ID
1353932
$ 436.80
1-2 weeks delivery time
-
+
The MARCO VP45-K electric vane pump is a 24V unit for diesel transfer with a free-discharge flow rate of 45 L/min and a cut-off pressure of 1.2 bar. It is self-priming up to 2 m and includes an integrated bypass for overpressure protection. The pump has 3/4 inch connections (listed as 3/4 inch (19 mm) and 3/4 inch BSPP), draws 4 A, measures 210 x 165 x 131 mm (H x W x L), and uses an aluminum body with resin rotor and blades, a stainless steel spindle, FKM seals, and an NBR O-ring; shipping weight is 7.70 kg.
- Description
- Ask a Question
-
VP45-K 24V Electric Vane Pump for Diesel Transfer
The MARCO 16602413 VP45-K is a self-priming electric vane pump designed for diesel transfer. It features an integrated bypass to help protect the system from excessive pressure build-up and is supplied as a complete set for refueling.
Technical Specifications
Flow Rate (Free Discharge) 45 L/min Cut-Off Pressure 1.2 bar Voltage 24V Current Consumption 4 A Self-Priming Up to 2 m Connection 3/4 inch (19 mm); 3/4 inch BSPP Dimensions (H x W x L) 210 x 165 x 131 mm Materials Aluminum body; resin rotor and blades; stainless steel spindle; FKM seals; NBR O-ring Product Portfolio Diesel transfer pumps Shipping Weight 7.70 kg
Features
- Integrated bypass helps protect against excessive pressure build-up
- Self-priming electric vane pump design
- On/off switch
- Dual connection option for hose holder
- Motor cover with EMI filter
- Complete set for refueling
Product Details
Flow rate is specified without back pressure (free discharge). If material compatibility with the pumped liquid is uncertain, verify compatibility of all wetted materials before operation.
-
