ID
1353930
$ 322.71
1-2 weeks delivery time
-
+
The MARCO VP45 self-priming electric vane pump is a 24V unit rated at 45 L/min (free discharge) with a 1.2 bar cut-off pressure and integrated bypass protection. It features 3/4 inch connections (including 3/4 inch BSPP / 19 mm), draws 4A, and self-primes up to 2 m. Construction includes an aluminum body, resin rotor and blades, stainless steel spindle, FKM seals, and an NBR O-ring; dimensions are 210 x 165 x 131 mm with a shipping weight of 4.10 kg.
- Description
- Ask a Question
-
MARCO VP45 Self-Priming Vane Pump (24V)
The MARCO 16602013 VP45 is a self-priming electric vane pump with an integrated bypass valve to help protect against excessive pressure build-up. It is listed in the diesel transfer pumps product portfolio and is supplied with 3/4-inch connections for installation.
Technical Specifications
Flow Rate 45 L/min (free discharge / without back pressure) Cut-Off Pressure 1.2 bar Voltage 24V Current Consumption 4A Self-Priming Up to 2 m Connection 3/4 inch (19 mm); 3/4 inch BSPP Dimensions (H x W x L) 210 x 165 x 131 mm Body Material Aluminum Rotor and Blades Material Resin Spindle Material Stainless steel Seal Material FKM seals; NBR O-ring Shipping Weight 4.10 kg Brand MARCO Product Portfolio Diesel transfer pumps
Features
- Integrated bypass to help protect against excessive pressure build-up
- Self-priming performance up to 2 m
- On/Off switch
- Dual connection option for hose holder
- Motor cover with EMI filter
- Portable kit
Product Details
If you are unsure about material compatibility with the liquid being pumped, confirm compatibility of all wetted materials before putting the pump into operation.
-
