The Stork Pump KGEF 16-3 400 Volt is a compact and reliable self-priming centrifugal pump designed for handling dirty and contaminated liquids in various applications. It offers moderate flow rates up to 15,500 liters per hour at 5 meters head, powered by a 2.2 kW motor, with cast iron or bronze materials available, and is suitable for liquids up to 95°C.
- Description
- Ask a Question
-
Stork Pump KGEF 16-3 400 Volt
This reliable self-priming centrifugal pump is designed for handling dirty water and various contaminated liquids. Ideal for bilge, deck wash, dewatering, sprinkling, and fire extinguishing tasks, it offers robust performance and durable materials.
- Type: KGEF
- Colour: blue
- Pump type: self-priming centrifugal pump
- Impeller type: open impeller or closed impeller (closed cast iron impeller)
- Motor type: short circuit motor for 400 volt
- Fuse: not inbuilt
- Shaft seal: ceramic on carbon mechanical seal
- Material impeller: cast iron (bronze available on request)
- Material pump housing: cast iron (bronze available on request)
- Material pump shaft: chromed steel
- Liquids handled: contaminated liquids such as water, sea water, diesel, gas oil, and fuel oil (max temperature +95°C)
- Performance by head:
- 10 m head: 15,500 litres/hour
- 15 m head: 14,500 litres/hour
- 20 m head: 11,000 litres/hour
- 25 m head: 8,000 litres/hour
- 30 m head: 5,000 litres/hour
- Connections: 1.1/4" internal thread
- Dimensions (LxWxH): 500 x 225 x 280 mm
- Weight: 45 kg
- Amperage: 4.7 A+
- Shaft power: 2.2 kW, 3 hp, 2850 rpm
- Product code: 92.05.163
- Suction head: 8.5 m
- Pipe diameter pressure and suction: 1.1/4"
- Pump type: Dry set-up pump: self-priming
- Medium: Water
- Particle size: 6 mm
- Max discharge head: 34.0 m
- Voltage: 400 V
- Current: AC
- Frequency: 50 Hz
- Protection class: IP68
- Free flow: 15,500 L/hour
- Capacity at 5 meter: 15,500 L/hour
- Notes:
- Complete Ni-resist available on request
- Check amperage on motor's nameplate at start-up due to possible small differences
-
