The Marco UP10 gear pump (part number 16440013) is a 24V electric self-priming transfer unit rated for 18 L/min (free discharge) with a cut-off pressure of 5 bar. It features 3/8 inch connections (3/8 inch BSPP, 9.5 mm), draws 5 A, and is self-priming up to 3 m. Construction includes a nickel-plated brass housing, stainless steel spindle, bronze gears, FKM seals, and an NBR O-ring; overall size is 225 x 109 x 175 mm (H x W x L) with a shipping weight of 4.70 kg.
- Description
- Ask a Question
-
UP10 24V Self-Priming Gear Transfer Pump
The Marco 16440013 UP10 is a reversible, self-priming electric gear pump designed for liquid transfer applications, including diesel transfer. It is built with metal gears and sealing materials specified for the pump assembly and is designed to operate safely even during dry running.
Technical Specifications
Flow Rate 18 L/min (free discharge / without back pressure) Cut-Off Pressure 5 bar Voltage 24V Current Consumption 5 A Self-Priming Up to 3 m Connection 3/8 inch BSPP Connections (Scope of Delivery) 3/8 inch (9.5 mm) Dimensions (H x W x L) 225 x 109 x 175 mm Housing Material Nickel-plated brass Spindle Material Stainless steel Gear Material Bronze Seal Material FKM O-Ring Material NBR Product Portfolio Diesel transfer pumps Shipping Weight 4.70 kg
Features
- Self-priming design (up to 3 m)
- Dry-run safe
- Reversible operation
- Metal construction with bronze gears and nickel-plated brass housing
- Specified sealing system: FKM seals and NBR O-ring
Product Details
If there is any uncertainty about material compatibility between the pump components and the liquid being pumped, verify compatibility before operation.
-
