The MARCO UP10-P gear pump is a 24V electric self-priming pump rated for 18 L/min (free discharge) with a cut-off pressure of 5 bar. It features 3/8 inch connections (listed as 3/8 inch (9.5 mm) and 3/8 inch BSPP), draws 5 A, and is self-priming up to 3 m. Construction details include a nickel-plated brass housing, stainless steel spindle, PEEK helical gears, and an FKM seal; dimensions are 225 x 109 x 173 mm with a shipping weight of 4.70 kg.
- Description
- Ask a Question
-
MARCO UP10-P 24V Self-Priming Gear Pump
The MARCO 16440213 UP10-P is an electric gear pump designed for liquid transfer in water pressure system applications. It uses a helical gear design and a corrosion-resistant metal housing, and is built to self-prime for easier installation and operation.
Technical Specifications
Flow Rate 18 L/min (free discharge / without back pressure) Cut-Off Pressure 5 bar Voltage 24V Current Consumption 5 A Self-Priming Up to 3 m Connection (Listed) 3/8 inch (9.5 mm) Connection 3/8 inch BSPP Dimensions (H x W x L) 225 x 109 x 173 mm Housing Material Nickel-plated brass Spindle Material Stainless steel Gear Type PEEK helical gear Seal Material FKM Shipping Weight 4.70 kg Product Portfolio Water Pressure Systems Brand MARCO
Features
- Flow rate of 18 liters per minute with free discharge (without back pressure)
- Self-priming up to 3 m
- 3/8 inch connections (as listed in the scope of delivery)
- Nickel-plated brass housing with stainless steel spindle
- FKM seal and PEEK helical gear design
Product Details
If there is any uncertainty about material compatibility between the pump and the pumped liquid, check compatibility of the materials in contact with the liquid before operation.
-
