ID
1353896
$ 190.69
1-2 weeks delivery time
-
+
The MARCO UP2-P electric gear pump is a 24V unit rated for 10 L/min (free discharge) with a cut-off pressure of 1.5 bar. It is self-priming up to 1.5 m, draws 3 A, and uses 3/8 inch connections (3/8 inch BSPP; 9.5 mm). Construction details include a nickel-plated brass housing, stainless steel spindle, PEEK helical gears, an FKM seal, and HNBR specified for this version; dimensions are 126 x 76 x 116 mm with a shipping weight of 1.60 kg.
- Description
- Ask a Question
-
MARCO UP2-P Electric Gear Pump (24V)
The MARCO 16420213 UP2-P is a self-priming gear pump for fluid transfer in water pressure system applications. It uses helical PEEK gears and compact, durable construction for installation where a small 24V pump is required.
Technical Specifications
Voltage 24V Flow Rate 10 L/min (free discharge / without back pressure) Cut-Off Pressure 1.5 bar Self-Priming Up to 1.5 m Current Consumption 3 A Connection 3/8 inch BSPP Connections (Scope of Delivery) 3/8 inch (9.5 mm) Dimensions (H x W x L) 126 x 76 x 116 mm Housing Material Nickel-plated brass Spindle Material Stainless steel Gear Type PEEK helical gear Seal Material FKM Material (Specified) HNBR Product Portfolio Water Pressure Systems Shipping Weight 1.60 kg
Features
- Self-priming electric gear pump
- 10 L/min flow rate at free discharge (without back pressure)
- Self-priming up to 1.5 m
- 3/8 inch connection size (3/8 inch BSPP; 9.5 mm)
- Nickel-plated brass housing with stainless steel spindle
- PEEK helical gears with FKM seal
Product Details
If there are uncertainties regarding material compatibility with the pumped liquid, check compatibility of the pump materials in contact with the fluid before operation.
-
