The MARCO UP12-P gear pump (part number 16430213) is a 24V electric self-priming pump rated for 36 L/min at free discharge (without back pressure) and a cut-off pressure of 2 bar. It features 1/2 inch connections (1/2 inch BSPP), draws 14A, and is self-priming up to 3 m. Construction includes a nickel-plated brass housing, stainless steel spindle, PEEK helical gears, and an FKM seal; dimensions are 233 x 113 x 197 mm (H x W x L) with a shipping weight of 5.30 kg.
- Description
- Ask a Question
-
MARCO UP12-P 24V Gear Pump Assembly
The MARCO 16430213 UP12-P is a self-priming electric gear pump designed for water pressure system applications. It delivers high flow at free discharge and uses helical gears with specified metallic and elastomeric materials for the wetted components.
Technical Specifications
Flow Rate (Free Discharge) 36 L/min (without back pressure) Cut-Off Pressure 2 bar Voltage 24V Current Consumption 14A Self-Priming Up to 3 m Connection 1/2 inch BSPP Connections (Scope of Delivery) 1/2 inch (12.7 mm) Dimensions (H x W x L) 233 x 113 x 197 mm Housing Material Nickel-plated brass Spindle Material Stainless steel Seal Material FKM Gear Type PEEK helical gear Shipping Weight 5.30 kg Product Portfolio Water Pressure Systems Brand MARCO
Features
- 36 L/min flow rate at free discharge (without back pressure)
- Self-priming up to 3 m
- 1/2 inch connections
- Nickel-plated brass housing with stainless steel spindle and FKM seal
- PEEK helical gear electric pump design
Product Details
If you are unsure about material compatibility between the pump and the pumped liquid, verify compatibility of the materials in contact with the medium before operation.
-
