ID
1353895
$ 195.58
1-2 weeks delivery time
-
+
The MARCO UP2 electric gear pump is a 24V unit for diesel transfer with a flow rate of 10 L/min (free discharge/without back pressure) and a cut-off pressure of 1.5 bar. It is self-priming up to 1.5 m, dry-run safe, and reversible, with 3/8 inch connections (3/8 inch BSPP; 9.5 mm). The pump draws 3 A and uses a nickel-plated brass housing, stainless steel spindle, bronze gears, FKM seals, and an NBR O-ring; dimensions are 126 x 76 x 116 mm (H x W x L) and shipping weight is 1.60 kg.
- Description
- Ask a Question
-
MARCO UP2 24V Diesel Transfer Gear Pump
The MARCO 16420013 is a self-priming electric gear pump designed for transferring diesel. It is reversible, dry-run safe, and built with corrosion-resistant metals and compatible seal materials as specified by the manufacturer.
Technical Specifications
Output 10 L/min (free discharge/without back pressure) Cut-Off Pressure 1.5 bar Voltage 24V Current Consumption 3 A Self-Priming Up to 1.5 m Connection 3/8 inch BSPP Connections (Scope of Delivery) 3/8 inch (9.5 mm) Dimensions (H x W x L) 126 x 76 x 116 mm Shipping Weight 1.60 kg Housing Material Nickel-plated brass Shaft Material Stainless steel Gear Material Bronze Seal Material FKM O-Ring Material NBR Product Portfolio Diesel transfer pumps Brand MARCO
Features
- Self-priming electric gear pump
- Dry-run safe
- Reversible operation
- Designed for transferring diesel
Product Details
If there is any uncertainty about material compatibility between the pump components and the pumped liquid, confirm compatibility before commissioning.
-
