ID
1353879
$ 308.04
1-2 weeks delivery time
-
+
The MARCO UP3-R gear pump (part number 16400813) is a 24V DC self-priming transfer unit rated for 15 L/min (free discharge) with a cut-off pressure of 2 bar. It features 3/8 inch connections (listed as 3/8 inch (9.5 mm) and 3/8 inch BSPP), draws 3A, and includes an On/Off 3-position reversing switch for reversible operation. Construction includes a nickel-plated brass housing, stainless steel spindle, bronze gears, FKM seals, and an NBR O-ring; dimensions are 180 x 89 x 114 mm and shipping weight is 2.30 kg.
- Description
- Ask a Question
-
UP3-R 24V DC Reversible Gear Transfer Pump
The MARCO UP3-R is a self-priming electric gear pump designed for liquid transfer, listed in the diesel transfer pump portfolio. It is reversible and includes a 3-position reversing switch, with a construction intended for reliable operation including dry-run capability.
Technical Specifications
Brand MARCO Part Number 16400813 Model UP3-R Voltage 24V DC Current Consumption 3 A Flow Rate 15 L/min (free discharge / without back pressure) Cut-Off Pressure 2 bar Self-Priming Up to 1.5 m Connection 3/8 inch BSPP Connections (Scope of Delivery) 3/8 inch (9.5 mm) Dimensions (H x W x L) 180 x 89 x 114 mm Shipping Weight 2.30 kg Materials Nickel-plated brass housing; stainless steel spindle; bronze gears; FKM seals; NBR O-ring Switch On/Off 3-position reversing switch Product Portfolio Diesel transfer pumps
Features
- Self-priming electric gear pump
- Reversible operation
- Dry-run safe
- Rated 15 L/min flow (free discharge)
Product Details
If you are unsure about material compatibility with the liquid being pumped, verify compatibility of all pump materials that contact the liquid before putting the pump into operation.
-
