ID
1353880
$ 283.60
1-2 weeks delivery time
-
+
The Marco UP3/OIL gear pump is a 24V electric pump for transferring oils or viscous liquids, rated for 5.5 L/min (free outlet/without back pressure) and 2 bar cut-off pressure. It is self-priming up to 1 m, dry-run safe, and reversible, with 3A current consumption and 3/8 inch connections (3/8 inch BSPP, 9.5 mm). Construction includes a nickel-plated brass housing, stainless steel spindle, FKM seals, NBR O-rings, and bronze gears; dimensions are 138 x 89 x 108 mm and shipping weight is 1.80 kg.
- Description
- Ask a Question
-
Marco UP3/OIL 24V Reversible Gear Pump
The Marco 16402013 UP3/OIL is a self-priming gear pump designed for transferring oils or viscous liquids. It is built with robust metallic internals and sealing materials for demanding fluid-handling tasks, and it can run in either direction for flexible installation and use.
Technical Specifications
Voltage 24V Output 5.5 L/min (free outlet/without back pressure) Cut-Off Pressure 2 bar Current Consumption 3 A Self-Priming Up to 1 m Connection 3/8 inch BSPP Connections (Scope of Delivery) 3/8 inch (9.5 mm) Dimensions (H x W x L) 138 x 89 x 108 mm Housing Material Nickel-plated brass Spindle Material Stainless steel Seal Material FKM seals, NBR O-rings Gears Bronze Product Portfolio Oil change pumps Shipping Weight 1.80 kg
Features
- Self-priming operation (up to 1 m)
- Dry-run safe
- Reversible rotation
- Designed for transferring oils or viscous liquids
- Gear pump design with bronze gears
Product Details
If you are unsure about material compatibility between the pump and the liquid being pumped, verify compatibility of all wetted materials before operation.
-
