Italwinch Devon Horizontal Drum Anchor Windlass 12V/24V, 1000W–1500W

ID 1379731

$ 2,802.92

1-2 weeks delivery time

Voltage:

Power, W

1000
1500

Size, mm:

The Italwinch Devon Horizontal Anchor Windlass is a heavy-duty horizontal windlass designed for intensive anchoring on boats up to 15 meters. Built with an anodized aluminium housing and chrome-plated brass gypsy and drum, the Devon series is available in 12V and 24V versions with 1000W and 1500W motors. Depending on the configuration, it supports 8 mm or 10 mm anchor chain and delivers up to 570 kg maximum pull, 190 kg working load, and up to 1500W of anchoring power. The windlass includes an integrated chain counter sensor and is supplied complete with relay and drum.

Description
Ask a Question

Italwinch Devon Horizontal Anchor Windlass 12V/24V, 1000W–1500W for Boats up to 15 m

The Italwinch Devon Horizontal Windlass is a robust electric anchor windlass developed for intensive marine use on motorboats and sailing yachts up to 15 metres in length. Its horizontal configuration is ideal where below-deck installation space is limited while still providing dependable anchoring performance.

The windlass features a durable anodized aluminium housing combined with a chrome-plated brass gypsy and drum for excellent corrosion resistance. Available with powerful 1000W and 1500W motors in both 12V and 24V versions, the Devon series supports 8 mm and 10 mm anchor chain depending on the selected model.

Designed for reliable everyday operation, the Devon windlass incorporates an integrated chain counter sensor and IP66 protected motor. Every unit is supplied complete with relay and drum, providing an efficient anchoring solution for recreational and professional vessels.

Key Features

Horizontal electric anchor windlass
Suitable for boats up to 15 metres
Anodized aluminium housing
Chrome-plated brass gypsy and drum
Available in 12V and 24V versions
1000W and 1500W motor options
Compatible with 8 mm or 10 mm anchor chain
Integrated chain counter sensor
IP66 protected motor
Supplied complete with relay and drum
Designed for intensive anchoring applications

Technical Specifications

Motor Power	Voltage	Chain Size	Maximum Pull	Working Load	Current Draw	Suitable Boats
1000 W	12V	8 mm	450 kg	150 kg	115 A	Up to 15 m
1000 W	24V	8 mm	480 kg	150 kg	60 A	Up to 15 m
1500 W	12V	8 mm	540 kg	180 kg	130 A	Up to 15 m
1500 W	12V	10 mm	540 kg	180 kg	130 A	Up to 15 m
1500 W	24V	8 mm	570 kg	190 kg	70 A	Up to 15 m
1500 W	24V	10 mm	570 kg	190 kg	70 A	Up to 15 m
