The STA-LOK UB20 Bronze U-Strap Toggle & Blank is a bronze turnbuckle fitting designed for longer chain plates. Forged from high strength bronze alloy and finished with a high quality polished chromium finish, it provides full articulation in two planes and is described as stronger than the wire rope. The range is available with UNF threads from 1/4" to 5/8".
- Description
- Ask a Question
-
STA-LOK UB20 Bronze U-Strap Toggle & Blank – Bronze Turnbuckle for Longer Chain Plates
The STA-LOK UB20 Bronze U-Strap Toggle & Blank is a bronze turnbuckle fitting designed for marine rigging applications where a forged U-strap toggle is required for longer chain plates. Forged from high strength bronze alloy, it provides durability, reliable articulation, and corrosion resistance in demanding marine environments.
The fitting features a high quality polished chromium finish and an elegant design suitable for traditional and modern marine rigging systems. According to the supplied data, the fitting is stronger than the wire rope.
Its toggle design allows full articulation in two planes, helping to maintain proper alignment under load and reducing stress on connected components.
Key Features
- Bronze U-Strap Toggle & Blank fitting
- Forged from high strength bronze alloy
- High quality polished chromium finish
- Full articulation in two planes
- Designed for longer chain plates
- Described as stronger than the wire rope
Available Variants
Item Number Thread (UNF) Toggle Width (mm) Toggle Pin (mm) Adjustment (mm) STUB20-1/4 1/4" 7.6 6.4 76.0 STUB20-5/16 5/16" 9.2 7.9 83.0 STUB20-3/8 3/8" 10.8 9.5 92.0 STUB20-7/16 7/16" 12.3 11.1 100.0 STUB20-1/2 1/2" 13.0 12.7 104.0 STUB20-5/8 5/8" 18.0 16.0 126.0
Technical Information
- Product type: Bronze U-Strap Toggle & Blank
- Material: High strength bronze alloy
- Finish: Polished chromium finish
- Application: Marine rigging and longer chain plate installations
- Movement: Full articulation in two planes
-
