ID
1355601
$ 86.30
1-2 weeks delivery time
Diameter, mm:
- 3
- 4
- 5
- 6
- 7
- 8
- 10
- 12
Item:
- 5/16
- 1/4
- 3/8
- 7/16
- 1/2
- 5/8
- 3/4
The STA-LOK B24 Bronze Toggle & Swage range consists of bronze turnbuckle assemblies supplied with a Threaded Strap Toggle (B18) at one end and a Swage Stud (051) at the other. Forged from high strength bronze alloy and finished with a high quality polished chromium finish, these assemblies are designed for wire rope tensioning in marine rigging applications. The toggle design provides full articulation in two planes, and the assemblies are described as stronger than the wire rope.
- Description
- Ask a Question
-
STA-LOK B24 Bronze Toggle & Swage – Bronze Turnbuckle Assemblies with Toggle and Swage Stud
The STA-LOK B24 Bronze Toggle & Swage range consists of bronze turnbuckle assemblies designed for marine rigging and wire rope tensioning applications. Each assembly is supplied with a Threaded Strap Toggle (B18) at one end and a Swage Stud (051) at the other.
Forged from high strength bronze alloy and finished with a high quality polished chromium finish, these turnbuckles provide durability, corrosion resistance, and a refined appearance for demanding marine environments.
The toggle arrangement provides full articulation in two planes, helping to maintain proper alignment under load. According to the supplied data, the assembly is stronger than the wire rope.
Key Features
- Bronze turnbuckle assembly with toggle and swage stud
- Supplied with Threaded Strap Toggle (B18) and Swage Stud (051)
- Forged from high strength bronze alloy
- High quality polished chromium finish
- Toggle action provides full articulation in two planes
- Designed for marine rigging and wire rope tensioning
Available Variants
Item Number Wire Size (Metric) Wire Size (Imperial) Thread (UNF) Fully Open (mm) Fully Closed (mm) Toggle Width (mm) Toggle Pin (mm) STB24-03-1/4 3 mm 1/8" 1/4" 232.0 156.0 6.4 6.4 STB24-04-1/4 4 mm 5/32" 1/4" 243.0 167.0 6.4 6.5 STB24-04-5/16 4 mm 5/32" 5/16" 261.0 178.0 8.4 7.9 STB24-05-5/16 5 mm 3/16" 5/16" 261.0 178.0 8.4 7.9 STB24-05-3/8 5 mm 3/16" 3/8" 284.0 192.0 9.9 9.5 STB24-06-3/8 6 mm - 3/8" 289.0 197.0 9.9 9.5 STB24-06-7/16 6 mm - 7/16" 316.0 216.0 11.5 11.1 STB24-07-7/16 7 mm 9/32" 7/16" 323.0 223.0 11.5 11.1 STB24-07-1/2 7 mm 9/32" 1/2" 343.0 239.0 13.1 12.7 STB24-08-1/2 8 mm 5/16" 1/2" 344.0 240.0 13.1 12.7 STB24-08-5/8 8 mm 5/16" 5/8" 415.0 289.0 16.3 16.0 STB24-10-5/8 10 mm - 5/8" 421.0 295.0 16.3 16.0 STB24-12-3/4 12 mm - 3/4" 537.0 369.0 19.1 18.5
Technical Information
- Product type: Bronze toggle and swage turnbuckle assembly
- Material: High strength bronze alloy
- Finish: Polished chromium finish
- End fittings: Threaded Strap Toggle (B18) and Swage Stud (051)
- Articulation: Full movement in two planes
- Application: Marine rigging and wire rope tensioning
-
