ID
1353886
$ 436.80
1-2 weeks delivery time
-
+
The Marco UP6-P electric gear pump (part number 16406513) is a 24V unit rated for 26 L/min (free discharge/without back pressure) and 2 bar. It is self-priming up to 1.5 m, draws 5 A, and uses 1/2 inch (12.7 mm) connections. Construction includes a nickel-plated brass housing, stainless steel shaft, and an FKM seal; overall size is 206 mm (H) x 111 mm (W) x 197 mm (L) with a shipping weight of 3.90 kg.
- Description
- Ask a Question
-
UP6-P 24V Electric Gear Pump Assembly
The Marco 16406513 UP6-P is a self-priming electric gear pump designed for transferring liquids using a compact, helical gear design. It features a robust metal housing and is intended for installations requiring 24V operation, a 1/2 inch connection size, and controlled delivery up to 2 bar.
Technical Specifications
Model UP6-P Voltage 24V Flow Rate 26 L/min (free discharge / without back pressure) Max Pressure 2 bar Self-Priming Up to 1.5 m Current Consumption 5 A Connections 1/2 inch (12.7 mm) Dimensions (H x W x L) 206 x 111 x 197 mm Housing Material Nickel-Plated Brass Shaft Material Stainless Steel Seal Material FKM Gear Type PEEK Helical Gear Shipping Weight 3.90 kg
Features
- Self-priming design (up to 1.5 m)
- 26 L/min flow rate at free discharge (without back pressure)
- 1/2 inch (12.7 mm) connections
- Nickel-plated brass housing with stainless steel shaft and FKM seal
- PEEK helical gear electric pump design
Product Details
If you are unsure about material compatibility between the pump and the liquid being transferred, verify compatibility of all wetted materials before operation.
-
