ID
1353889
$ 345.54
1-2 weeks delivery time
-
+
The Marco UP8 gear pump is a 24V electric self-priming transfer unit rated for 10 L/min (free discharge/without back pressure) with a 4 bar cut-off pressure. It uses a nickel-plated brass housing, stainless steel spindle, bronze gears, FKM seals, and an NBR O-ring, and it is dry-run safe and reversible. The pump has 3/8 inch BSPP connections (3/8 inch / 9.5 mm), draws 5.5 A, measures 176 x 101 x 166 mm, and has a shipping weight of 2.30 kg.
- Description
- Ask a Question
-
Marco UP8 24V Gear Transfer Pump
The Marco UP8 is a compact, self-priming electric gear pump designed for liquid transfer applications, including diesel transfer. It is reversible and built with robust metallic components and chemical-resistant sealing materials for demanding service.
Technical Specifications
Voltage 24V Output 10 L/min Flow Rating Basis Free discharge / without back pressure Cut-Off Pressure 4 bar Self-Priming Up to 1.5 m Current Consumption 5.5 A Connection 3/8 inch BSPP Connections (Scope of Delivery) 3/8 inch (9.5 mm) Materials Nickel-plated brass housing; stainless steel spindle; bronze gears; FKM seals; NBR O-ring Dimensions (H x W x L) 176 x 101 x 166 mm Shipping Weight 2.30 kg Product Portfolio Diesel transfer pumps
Features
- Self-priming electric gear pump
- Dry-run safe
- Reversible operation
- High load capacity with a compact footprint
- Designed with bronze gears and metal housing components
Product Details
If you are unsure about material compatibility with the liquid being pumped, confirm compatibility of all pump materials in contact with the pumped medium before operation.
-
