The MARCO UP3 gear pump (part no. 16400013) is a 24V electric self-priming transfer unit rated for 15 L/min (free discharge) with a 2 bar cut-off pressure. It is dry-run safe and reversible, with 3/8 inch BSPP connections and a current consumption of 3 A. Construction includes a nickel-plated brass housing, stainless steel spindle, bronze gears, FKM seals, and an NBR O-ring; dimensions are 162 x 101 x 166 mm and shipping weight is 2.50 kg.
- Description
- Ask a Question
-
MARCO UP3 24V Self-Priming Gear Pump
The MARCO 16400013 is an electric, self-priming gear pump intended for liquid transfer, listed in the diesel transfer pump portfolio. It is designed for efficient transfer operation with reversible running and dry-run safe capability.
Technical Specifications
Flow Rate (Free Discharge) 15 L/min Cut-Off Pressure 2 bar Voltage 24V Current Consumption 3 A Self-Priming Up to 1.5 m Connections 3/8 inch BSPP (3/8 inch / 9.5 mm) Materials Nickel-plated brass housing; stainless steel spindle; bronze gears; FKM seals; NBR O-ring Dimensions (H x W x L) 162 x 101 x 166 mm Shipping Weight 2.50 kg Product Portfolio Diesel transfer pumps
Features
- Dry-run safe
- Reversible operation
- Self-priming design (up to 1.5 m)
- Gear pump with bronze gears
Compatibility
- Alternative to Jabsco Junior Gear Puppy 23220-2024
Product Details
If there are uncertainties regarding material compatibility between the pump components and the pumped medium, compatibility should be confirmed before putting the pump into operation.
-
