ID
1316960
$ 199.08
1-2 weeks delivery time
-
+
The Wing Pump Sigma K-0 is a green self-priming wing pump featuring brass wings and valves with cast iron housing, delivering 11 litres per minute capacity with 1/2" connections, including wooden handle and flanges for drum pumping and bilge applications.
- Description
- Ask a Question
-
Wing Pump Sigma K-0 - 1/2"
This green Sigma pump model K-0 serves for pumping drums, bilge pumping in lifeboats and engine rooms, and flushing toilets. It features a self-priming double action wing pump with horizontal rotation and a stuffing box shaft seal. It includes a wooden handle and flanges.
- Type: Sigma
- Colour: green
- Pump type: self-priming double action wing pump if filled
- Impeller type: wing
- Rotation: horizontal movement
- Shaft seal: stuffing box
- Material wing: brass
- Material valves: brass
- Material pump housing: cast iron
- Material pump shaft: steel
- Suitable liquids: water, sea water, gas oil, petrol, petroleum and oils with max viscosity of 10, plus other clean and low viscosity media
- Capacity measured with water at 20°C and suction/discharge height of 100 cm
- Includes wooden handle and flanges
- Capacity: 11 litres per minute (65 strokes per minute)
- Suction height: 7 metres
- Installed length: 175 mm without flanges
- Weight: 5.1 kg
- Product code: 96.15.110
- Suction head: 7.0 m
- Pipe diameter pressure: 1/2"
- Pipe diameter suction: 1/2"
- Pump type: Hand pump, Vane pump
- Medium: Water, Gasoil, Lubricating oil
- Particle size: 2 mm
- Discharge head Max.: 25.0 m
- ATEX: No
- Free flow: 660 L/Hour
-
