ID
1316966
$ 1,236.38
1-2 weeks delivery time
-
+
The larger Sigma K-7 wing pump provides robust performance for similar applications with enhanced capacity. This green, self-priming double action wing pump handles the same range of clean, low viscosity liquids and features the same material construction with brass components, cast iron housing, and steel shaft. With a capacity of 90 liters per minute at 40 strokes per minute, it offers greater flow rates while maintaining horizontal rotation and the same 7-meter suction height capability.
- Description
- Ask a Question
-
Wing Pump Sigma K-7 - 2"
The green Sigma K-7 wing pump offers robust performance for pumping drums, bilge pumping on lifeboats and engine rooms, and flushing toilets. It is a self-priming double action wing pump with horizontal rotation, suitable for clean and low viscosity liquids such as water, sea water, gas oil, petrol, petroleum, and oils with viscosity up to 10.
- Type: Sigma
- Colour: green
- Pump type: self-priming double action wing pump if filled
- Impeller type: wing
- Rotation: horizontal movement
- Shaft seal: stuffing box
- Material wing: brass
- Material valves: brass
- Material pump housing: cast iron
- Material pump shaft: steel
- Liquids handled: water, sea water, gas oil, petrol, petroleum and oils (max viscosity 10), other clean low viscosity media
- Comes with: wooden handle and flanges
- Comment: capacity measured with water at 20°C and suction/discharge heights of 100 cm
- Capacity: 90 litres per minute (40 strokes per minute)
- Suction height: 7 metres
- Installed length: 360 mm without flanges
- Weight: 32 kg
- Product code: 96.15.117
- Suction head: 7.0 m
- Pipe diameter pressure: 2"
- Pipe diameter suction: 2"
- Pump type details: Hand pump, Vane pump
- Medium: Water, Gasoil, Lubricating oil
- Particle size: 2 mm
- Discharge head max.: 15.0 m
- Free flow: 5400 L/hour
- ATEX: No
-
