The Wing Pump Sigma K-2 is a green self-priming wing pump with 1" pipe connections, delivering 22 litres per minute capacity at 55 strokes per minute, weighing 8.8 kg and featuring brass components with cast iron housing for bilge and drum pumping applications.
- Description
- Ask a Question
-
Wing Pump Sigma K-2 - 1"
This green Sigma wing pump is designed for pumping out drums, use as a bilge pump in lifeboats and engine rooms, and flushing toilets. It features a self-priming double action wing pump mechanism with horizontal movement.
- Type: Sigma
- Colour: green
- Pump type: self-priming double action wing pump if filled
- Impeller type: wing
- Rotation: horizontal movement
- Shaft seal: stuffing box
- Material wing: brass
- Material valves: brass
- Material pump housing: cast iron
- Material pump shaft: steel
- Liquids: water, sea water, gas oil, petrol, petroleum and oils with max viscosity 10, and other clean low viscosity media
- Comes with: wooden handle and flanges
- Capacity: 22 litres per minute (55 strokes per minute)
- Suction height: 7 metres
- Installed length: 230 mm without flanges
- Weight: 8.8 kg
- Product code: 96.15.112
- Pipe diameter pressure: 1"
- Pipe diameter suction: 1"
- Pump type: Hand pump, Vane pump
- Mediums: Water, Gasoil, Lubricating oil
- Particle size max: 2 mm
- Discharge head max: 25.0 m
- Free flow: 1320 L/Hour
- Comment: Capacity measured with water at 20°C, suction and discharge heights of 100 cm
- ATEX: No
-
