ID
1316965
$ 522.14
1-2 weeks delivery time
-
+
The Sigma K-5 wing pump is a green, versatile hand pump designed for multiple applications including drum pumping, bilge pumping in lifeboats and engine rooms, and toilet flushing. This self-priming double action wing pump with horizontal rotation can handle clean, low viscosity liquids like water, seawater, gas oil, petrol, and petroleum oils up to viscosity 10. It features brass wings and valves, cast iron housing, steel shaft, wooden handle, and flanges, with a capacity of 53 liters per minute at 45 strokes per minute.
- Description
- Ask a Question
-
Wing Pump Sigma K-5 - 1.1/2"
This green Sigma wing pump is designed for versatile applications such as pumping out drums, bilge pumping in lifeboats and engine rooms, and flushing toilets. It operates as a self-priming double action wing pump with horizontal rotation and is suitable for clean, low viscosity liquids including water, sea water, gas oil, petrol, petroleum, and oils with viscosity up to 10.
- Type: Sigma
- Colour: green
- Pump type: self-priming double action wing pump if filled
- Impeller type: wing
- Rotation: horizontal movement
- Shaft seal: stuffing box
- Material wing: brass
- Material valves: brass
- Material pump housing: cast iron
- Material pump shaft: steel
- Liquids handled: water, sea water, gas oil, petrol, petroleum and oils (max viscosity 10), other clean low viscosity media
- Comes with: wooden handle and flanges
- Comment: capacity measured with water at 20°C and suction/discharge heights of 100 cm
- Capacity: 53 litres per minute (45 strokes per minute)
- Suction height: 7 metres
- Installed length: 320 mm without flanges
- Weight: 16 kg
- Product code: 96.15.115
- Suction head: 7.0 m
- Pipe diameter pressure: 1.1/2"
- Pipe diameter suction: 1.1/2"
- Pump type details: Hand pump, Vane pump
- Medium: Water, Gasoil, Lubricating oil
- Particle size: 2 mm
- Discharge head max.: 20.0 m
- Free flow: 3180 L/hour
- ATEX: No
-
