The Stork Pump KGEF 11-3/A7 230 Volt is a reliable self-priming centrifugal pump ideal for dirty water applications such as bilge pumping, deck washing, dewatering, sprinkling, and firefighting. It features an induction motor, open or closed polyamide impeller, and ceramic on carbon shaft seal. It handles contaminated liquids including seawater and fuels up to 95°C, operating at 230 V with a maximum discharge head of 15.5 meters.
- Description
- Ask a Question
-
Stork Pump KGEF 11-3/A7 230 Volt
This reliable self-priming pump is ideal for pumping dirty water and can be used for bilge, deck wash, dewatering, sprinkling, and fire extinguishing purposes.
- Type: KGEF
- Colour: blue
- Pump type: self-priming centrifugal pump
- Impeller type: open or closed impeller
- Motor type: induction motor
- Fuse: not inbuilt
- Shaft seal: ceramic on carbon mechanical seal
- Material impeller: polyamide
- Material pump housing: cast iron (bronze available on request)
- Material pump shaft: chromed steel
- Liquids handled: contaminated liquids including water, sea water, diesel, gas oil, and fuel oil (max temperature +95°C)
- Performance:
- 10 m head: 11,000 L/h
- 15 m head: 3,500 L/h
- Impeller: open polyamide impeller
- Particle size: up to 7.5 mm
- Connections: 1.1/4" internal thread
- Dimensions (LxWxH): 412 x 190 x 255 mm
- Weight: 24 kg
- Amperage: 5.5 A+
- Shaft power: 0.75 kW, 1 hp, 2850 rpm
- Product code: 92.05.112
- Suction head: 8.4 m
- Pipe diameter pressure: 1.1/4"
- Pipe diameter suction: 1.1/4"
- Pump type: Dry set-up pump, self-priming
- Medium: Water
- Particle size: 7 mm
- Discharge head Max.: 15.5 m
- Voltage: 230 V
- Current: AC
- Frequency: 50 Hz
- Protection class: IP68
- ATEX: No
- Notes:
- Complete Ni-resist also available
- Always check amperage on motor nameplate when starting pump as small differences exist among motors
-
