ID
1330948
$ 379.08
1-2 weeks delivery time
-
+
The SPX Johnson Pump 10-24569-01 F35B-8 bronze flexible-impeller pump assembly delivers self-priming circulation for marine engine cooling and other onboard transfer duties. A foot-mounted, base-mounted design with 3/8 in BSP female threaded ports, a mechanical seal, 1/1 cam, and stainless cover and wear plate supports reliable operation and long service life. The pump is supplied with an MC97 impeller and uses a single-flat, slotted-shaft pin drive arrangement with 11 mm and 12 mm shaft diameter references provided.
- Description
- Ask a Question
-
SPX Johnson Pump 10-24569-01 F35B-8 Bronze Impeller Pump Unit
The SPX Johnson Pump F35B-8 is a compact bronze flexible-impeller pump built for dependable seawater-capable service onboard. Its self-priming design, foot-mounted base, and robust internal components make it a strong choice for marine engine cooling upgrades or like-for-like replacements where consistent flow and durability matter.
Application
- Marine engine cooling (self-priming cooling water pump, size F35)
- Bilge pumping
- Deck washing
- Freshwater transfer
- Refueling/transfer duties
- Emptying wastewater tanks at the dock
- Flushing, filling, and rinsing water tanks
Compatibility
- Kubota OC60 engines (frequently used)
Technical Specifications
Brand SPX Johnson Pump Part Number 10-24569-01 Model F35B-8 Product Portfolio Cooling Water Pumps; Impeller Pumps Capacity 20.5 l/min Connection 3/8 in BSP Inlet/Outlet 3/8 in BSP Female Mounting Type Foot mounting (base-mounted) Drive Pulley drive Drive/Shaft End Single Flat Drive Impeller Hub Slotted Shaft Pin Drive Shaft Diameter (Provided) 11 mm; 12 mm (also listed as 12mm / 11mm and Ø12k6mm) Material (Body) Bronze Shaft Material Stainless steel Seal Type Mechanical seal Cam 1/1 cam Cover / Wear Plate Stainless steel cover and wear plate Dimensions 109 x 80 x 30 mm Shipping Weight 1.80 kg Weight (Also Listed) 0.5 kg EAN 8719182065869 Article Number (Also Listed) 66102456901
Product Details
- Self-priming flexible-impeller pump designed for dependable suction and onboard service
- Permanent-lubricated double ball bearings (as listed) support stable operation
- Supplied with MC97 impeller (also referenced as MC-97 and Art. 6609808B1)
- Connections use 3/8 in BSP female threaded ports (also described as internal thread / Rp 3/8 in)
Features
- Bronze construction for marine-duty use
- Mechanical seal and stainless cover/wear plate for longevity
- Foot-mounted base for straightforward installation
- Alternative to SPX Johnson Pump 10-35038-1
- OEM reference: 1829514
- Service kit reference: 09-46840
- Impeller kit reference: 09-810B-1
-
