The Simrad NAC-2 Autopilot Core Pack includes the NAC-2 autopilot computer, Precision-9 compass, and RF25 rudder feedback, for boats up to 10 m. It supports hydraulic and mechanical drives, providing stable autopilot control with plug-and-play installation and IPX7 components. Brand: Simrad, article 000-13335-001, barcode 9420024155639.
- Description
- Ask a Question
-
Simrad NAC-2 Autopilot Core Pack
The Simrad NAC-2 Autopilot Core Pack includes the NAC-2 autopilot computer, Precision-9 compass and RF25 rudder feedback unit. This system is designed for vessels up to 10 metres (33 feet) and supports low-current hydraulic drives, mechanical drives and solenoid valves.
The NAC-2 control algorithms ensure stable steering performance across different weather conditions and sea states. The system interfaces with heading sensors and rudder feedback units and provides reliable autopilot control for small boats.
NAC-2 Features
- Designed for boats up to 10 m (33 ft)
- Supports low-current hydraulic and mechanical drives
- 8A continuous output, 16A peak
- 12/24 V input
- Solenoid output capable
- 3A clutch output
- Optional Auto/Standby switch
- B&G Reflex sailing algorithms
- Plug and play installation
Precision-9 Compass Features
- Heading, rate of turn (ROT), pitch and roll output over NMEA 2000®
- Heading accuracy ±2° after calibration
- Solid-state sensor technology
- Adjustable mounting bracket
- IPX7 waterproof
- Single NMEA 2000® connection
RF25 Rudder Feedback Features
- ±120° measurement
- Accuracy ±0.5°
- SimNet connectivity
- 5.5 m attached SimNet cable
Technical Data
Article 000-13335-001 Series OR-2 Input Voltage 12 / 24 V Continuous Output 8 A Peak Output 16 A Clutch Output 3 A Maximum Vessel Length 10 m (33 ft) Sales Unit 1 Piece
Minimum product requirements: Requires a hydraulic steering pump or mechanical drive unit, and a compatible autopilot controller or networked multifunction display.
Brand: Simrad (Article Code: 000-13335-001) (Barcode: 9420024155639)
-
