Fischer Panda RD3.3 AC Roof-Mount Radiators for Vehicle Generators

ID 1385956

$ 4,479.35

1-2 weeks delivery time

Item:

RD3.3
RD3.3 Trop

Fischer Panda RD3.3 AC roof-mount radiators are designed for cooling compatible Fischer Panda vehicle generators and operate on 230 V / 50 Hz AC power. The range includes the RD3.3 AC and RD3.3 Trop AC versions, both measuring 1055 x 515 mm, with heights of 369 and 364 mm and weights of 36 and 42 kg respectively. Depending on the version, compatibility includes Fischer Panda 5000i, 8000i, 10000i, 15000i, 8000x, 10000x, 12000x and 15000x generators. The radiators are intended for installation where unrestricted fresh-air circulation is available, preferably horizontally on the vehicle roof, and feature an integrated expansion tank.

Description
Ask a Question

Fischer Panda RD3.3 AC Roof-Mount Radiators for Vehicle Generators

The Fischer Panda RD3.3 series consists of AC-powered roof-mount radiators designed for cooling compatible Fischer Panda vehicle generators. The radiators operate at 230 V / 50 Hz and are available in standard RD3.3 AC and RD3.3 Trop AC versions.

The radiator should be installed in a location with good access to fresh-air circulation. Horizontal installation on the roof of the vehicle is specified as the preferred mounting position. An expansion tank is integrated into the radiator.

Key Features

Roof-mount radiator system for compatible Fischer Panda vehicle generators
230 V / 50 Hz AC operation
Designed for installation with unrestricted fresh-air circulation
Horizontal vehicle roof installation recommended
Integrated expansion tank
Standard and Trop versions available

Available Models

Article Number	Model	Compatible Generators	Voltage / Frequency	Dimensions (L x W x H)	Weight
FPAC02001	RD3.3 AC	5000i, 8000i, 10000i, 15000i, 8000x, 10000x, 12000x, 15000x	230 V / 50 Hz	1055 x 515 x 369 mm	36 kg
FPAC02002	RD3.3 Trop AC	8000i, 10000i, 15000i, 8000x, 10000x, 12000x, 15000x	230 V / 50 Hz	1055 x 515 x 364 mm	42 kg
