ID
1385900
$ 12,698.63
1-2 weeks delivery time
Power, W
- 3.4 kW
- 6.8 kW
- 8.0 kW
- 10.2 kW
- 12.7 kW
- 15.3 kW
- 20.4 kW
- 25.5 kW
Item:
- 4.0 kVA
- 8.0 kVA
- 10.0 kVA
- 12.0 kVA
- 15.0 kVA
- 18.0 kVA
- 24.0 kVA
- 30.0 kVA
Fischer Panda xControl PMS is a range of fixed-speed 3000 RPM marine AC generators with power outputs from 6.8 kW / 8.0 kVA to 25.5 kW / 30 kVA. The range includes 2-, 3- and 4-cylinder configurations, with dimensions from 595 x 440 x 590 mm to 1010 x 515 x 670 mm. These generators use Fischer Panda's digital xControl system and can be configured with HP1 single-phase, HP3 three-phase or DVS mixed single- and three-phase dynamo options. Multiple xControl generators can be connected in parallel for peak power, load sharing and improved weight distribution.
- Description
- Ask a Question
-
Fischer Panda xControl PMS Marine AC Generators 6.8–25.5 kW, 3000 RPM
The Fischer Panda xControl PMS range consists of fixed-speed marine AC generators operating at 3000 RPM, with power ratings from 6.8 kW / 8.0 kVA up to 25.5 kW / 30 kVA. The range includes models with 2-, 3- and 4-cylinder configurations to cover different onboard power requirements.
These generators incorporate Fischer Panda's digital xControl system. Multiple xControl generators with different outputs can be connected in parallel, providing additional capacity for peak loads as well as improved weight distribution and load sharing.
xControl System and Dynamo Options
- Fixed-speed 3000 RPM generator concept
- Digital Fischer Panda xControl system
- Multiple xControl generators can be connected in parallel
- Parallel operation can be used for peak power requirements, weight distribution and load sharing
- HP1 dynamo option: single-phase
- HP3 dynamo option: three-phase
- DVS dynamo option: combined single-phase and three-phase
- 120 V / 60 Hz options are also available
Available Models
Article Number Model Power RPM Cylinders Dimensions (L x W x H) FPMA3003 Fischer Panda 8000x PMS 6.8 kW / 8.0 kVA 3000 2 595 x 440 x 590 mm FPMA3015 Fischer Panda 10000x PMS 8.0 kW / 10.0 kVA 3000 2 705 x 445 x 590 mm FPMA3004 Fischer Panda 12000x PMS 10.2 kW / 12.0 kVA 3000 3 705 x 445 x 590 mm FPMA3005 Fischer Panda 15000x PMS 12.7 kW / 15.0 kVA 3000 3 730 x 470 x 600 mm FPMA3006 Fischer Panda 18 PMS 15.3 kW / 18.0 kVA 3000 3 830 x 515 x 660 mm FPMA3007 Fischer Panda 24 PMS 20.4 kW / 24.0 kVA 3000 4 1010 x 515 x 670 mm FPMA3008 Fischer Panda 30 PMS 25.5 kW / 30 kVA 3000 4TD 1010 x 515 x 670 mm -
