Maxwell VWC Series Vertical Windlass VWCLP, article P100423, is a 12V vertical anchor windlass with a 1000W heavy-duty motor, designed for automatic handling of chain-only anchor rodes. The unit features an independent capstan for hauling a secondary rope/chain rode or for assisting docking operations, supports chain sizes from 6 to 10 mm, delivers a maximum pull of 700 kg, and has a total weight of 24 kg.
- Description
- Ask a Question
-
Maxwell VWC Series Vertical Windlass 1000W 12V with Independent Capstan
The Maxwell VWC Series vertical windlass is engineered for fully automatic vertical handling of chain-only anchor rodes. The design incorporates an independent capstan, allowing retrieval of a secondary rope or chain rode and providing additional support during docking maneuvers. High-quality marine-grade materials and a modular installation concept ensure reliable long-term operation in demanding marine environments.
Key Features
- Designed for automatic vertical handling of chain-only anchor rodes
- Independent capstan for secondary rope or chain hauling and docking assistance
- Fully automatic single or dual direction chainwheel operation
- Above-deck components manufactured from marine-grade stainless steel (AISI 316)
- Integral chain pipe and stripper aligned for virtually jam-free chain operation
- Automatic feed of chain into and out of the anchor locker
- Cone-type brake and clutch mechanism allowing manual free-fall anchoring
- Smooth, progressive clutch engagement for precise operator control
- Chainwheel locking pawl for added operational security
- Clutch disengagement enables independent rope hauling using the warping drum
- Modular through-deck installation with precise gearbox alignment
- Anodized aluminium gearbox and spacer tube on all models
- Heavy-duty dual direction motor designed specifically for marine winch applications
Technical Specifications
Parameter Value Article Number P100423 Motor Power 1000 W Voltage 12 V Configuration Vertical Rode Type Chain Warping Drum No Maximum Pull / Lift 700 kg Supported Chain Size 6 – 10 mm (short link) Weight 24 kg
Construction and Installation
- Marine-grade stainless steel fasteners for corrosion resistance
- Through-deck installation enabled by modular construction
- Gearbox precisely aligned to topworks for reliable power transmission
- Low-profile configurations available without warping drum
-
