ID
1341268
$ 2,108.72
1-2 weeks delivery time
-
+
JL Audio MV800/8i 8-Channel Amplifier delivers reference-grade marine audio using NexD2 technology and integrated DSP, offering powerful multi-channel output with advanced digital control and networking.
- Description
- Ask a Question
-
JL Audio 010-03339-00 - MV800/8i 8-Channel Amplifier
The JL Audio MV800/8i is engineered to deliver reference-grade audio performance in demanding marine environments. It combines advanced NexD2™ switching amplifier technology with a fully integrated digital signal processor, providing exceptional sound quality, efficiency, and system control.
This 8-channel amplifier delivers powerful and clean output while maintaining very low noise and distortion. All amplifier adjustments and DSP functions are configured digitally via an external device using JL Audio’s TüN® software, eliminating the need for traditional control knobs and switches.
Housed in a compact cast-alloy chassis with a marine-grade powder-coated finish, the MV800/8i features corrosion-resistant hardware and connectors, ensuring long-term durability in harsh conditions.
Key Features
- Integrated onboard DSP for timing, frequency response, and output level optimization
- Second-generation NexD2™ switching amplifier technology
- DSP-controlled full-range amplification with DirectFET™ outputs
- Configuration via JL Audio TüN® software on PC, tablet, or smartphone
- Differential-balanced analog inputs with high noise rejection
- JLid™ system command and control with networking capability
Audio Performance
Channels 8-Channel Rated Power @ 4 Ohm 8 x 75 W Rated Power @ 2 Ohm 8 x 100 W Bridged Power @ 4 Ohm 4 x 200 W Frequency Response 12 Hz – 21 kHz Signal-to-Noise Ratio (Reference Max Power) 99 dB Signal-to-Noise Ratio (Reference 1 W) 80 dB Damping Factor @ 4 Ohm > 100 / 50 Hz Damping Factor @ 2 Ohm > 50 / 50 Hz Total Harmonic Distortion < 1% @ 2 Ohm per Channel RCA Input Voltage Range 250 mV – 16 V RMS
Connectivity And Control
DSP Configuration Via External Device Using JL Audio TüN® Software Analog Pre-Outs Independent DSP Processing, 4 V RMS Max JLid™ Networking Supports Multi-Amplifier Control And Preset Management Included Accessories Power Connector (4 AWG), 2 Speaker Output Harnesses, 6 ft A/B USB Cable
Dimensions And Technical Data
Height 52 mm Width 355 mm Depth 176 mm Weight 2.54 kg Total Power 800 W Voltage 12 V
Brand: JL Audio
Barcode: 0699440986496 -
