ID
1341273
$ 778.78
1-2 weeks delivery time
-
+
JL Audio XDM600/1 is a slim Class D monoblock amplifier built to deliver strong, controlled bass with up to 600 W output. Its compact chassis, wide voltage stability, and high damping factor make it ideal for powering marine subwoofers with clarity and efficiency.
- Description
- Ask a Question
-
JL Audio 010-03116-00 - Amplifier XDM600/1 600W
The JL Audio XDM600/1 is a compact yet powerful Class D monoblock amplifier designed to deliver clean and efficient 600 W performance. Built for flexibility and reliability, it supports a wide operating voltage range and is engineered to maintain excellent sound quality with low distortion and high damping factor. Its slim chassis allows easy installation while still providing the robust power needed for demanding audio systems.
General Specifications
Channels Monoblock / 2 / 3 / 4 / 5 / 6 / 8 Amplifier Class Class D Operating Voltage 11–14.5 VDC (12 V Models) Warranty 3 Years Color Black
Physical Dimensions
Height 2.05" (52 mm) Width Monoblock (600 W): 8.52" (216 mm) Depth 7.09" (180 mm) Weight 6.3 lbs (2.86 kg)
Rated Continuous Power (RMS)
14.4 V @ 4 Ω 400 W x 1 14.4 V @ 2 Ω 600 W x 1 12.5 V @ 4 Ω 300 W x 1 12.5 V @ 2 Ω 500 W x 1
Audio Performance
Signal-to-Noise Ratio (Rated Power) > 87 dB Signal-to-Noise Ratio (1 W) > 67 dB Damping Factor @ 4 Ω > 1000 / 50 Hz Damping Factor @ 2 Ω > 500 / 50 Hz THD+N @ Rated Power < 1% @ 2 Ω Frequency Response 7 Hz – 500 Hz
Inputs And Electrical
Input Voltage Range (RCA) 200 mV – 4 V RMS Fuse Rating 50 A Recommended Fuse Type AFS, AGU or MaxiFuse™ Minimum Power/Ground Wire Gauge 4 AWG
Additional Data
Power 600 W Voltage 12 V Width (Listed) 260 mm Height (Listed) 52 mm Depth (Listed) 180 mm Weight (Listed) 2.63 kg
Brand: JL Audio
Barcode: 010-03116-00 -
