Jabsco 37010-3092 - Toilet 12V - Compact Bowl

Jabsco 37010-3092 - Toilet 12V - Compact Bowl

The Jabsco 37010-3092 12V Compact Bowl Toilet is a high-performance and space-efficient marine toilet designed for easy installation in boats, RVs, and other mobile systems. This compact model offers powerful waste disposal through its high-capacity macerator pump and flexible impeller flush system. With its white vitreous china bowl and baked enamel seat & cover, the toilet is built for durability and easy maintenance. The included momentary control switch makes operation straightforward, while the unit's design ensures quiet and reliable flushing. It is compatible with 19mm (¾”) bore inlet hoses and 25mm (1”) bore discharge hoses, with the option to adapt to 38mm (1-1/2") waste plumbing. The Jabsco 37010-3092 offers a perfect balance of efficiency, compactness, and reliability, making it ideal for marine and RV use.

Key Features:

• 12V electric operation for consistent and efficient waste management
• High-capacity macerator pump and bowl scavenger pump for powerful waste disposal
• Flexible impeller flush pump ensures smooth operation and efficient water flow
• Compact white vitreous china bowl for durability and easy cleaning
• Baked enamel seat & cover for extra durability and a smooth, easy-to-maintain surface
• Momentary control switch for simple, user-friendly operation
• Connections for 19mm (¾”) bore inlet hose and 25mm (1”) bore discharge hose
• Adapter included for 38mm (1-1/2") waste plumbing compatibility
• Amperage: 16A with a 25A fuse size for safe operation
• Compact design for easy installation in smaller spaces

Specifications:

• Fuse Size: 25A
• Maximum Current: 16A
• Dimensions: Height: 355mm, Width: 352mm, Depth: 451mm
• Connections: Inlet hose (16mm or 19mm), Discharge hose (25mm)
• Thru Flow: 0.9 to 1.4 liters per 5 seconds of operation
• Material: White vitreous china bowl, baked enamel seat & cover
• Momentary Control Switch: Included for easy operation
• Hose Adapter: Included to adapt to 38mm (1-1/2") waste plumbing
• Weight: 14.5 kg (Approx. 15.5 kg packed)
• Packaged Dimensions: L: 54.00 cm x H: 54.00 cm x W: 50.00 cm
• Operating Voltage: 12V DC
• Max Operating Pressure: 25 PSI
• Quiet Operation: Includes noise-dampening features for smooth operation
• Designed for Marine and RV use
• Alternate to Jabsco 37010-0090

Compatibility and Application:

The Jabsco 37010-3092 Compact Bowl Toilet is ideal for boats, yachts, RVs, and other mobile systems where space is limited but high-performance sanitation is essential. The 12V DC operation ensures consistent performance with minimal energy consumption. With its compact size and powerful macerator pump, this toilet can be easily installed in smaller compartments, while the flexible impeller system guarantees smooth waste removal. The inclusion of a hose adapter for 38mm (1-1/2") plumbing ensures compatibility with existing plumbing systems, making the Jabsco 37010-3092 a versatile and easy-to-integrate solution.

Benefits:

• Efficient, space-saving design ideal for smaller areas in boats and RVs
• High-capacity macerator pump ensures powerful and thorough waste disposal
• Quiet, reliable operation due to advanced flush system and noise-dampening features
• Durable and easy-to-clean white vitreous china bowl and baked enamel seat & cover
• Convenient, simple operation with a momentary control switch
• Inlet hose connections compatible with 16mm or 19mm hoses, and discharge hose compatible with 25mm
• Adapter for 38mm (1-1/2") waste plumbing included for easy setup
• 16A amperage with 25A fuse size ensures safe and reliable use
• Compact, lightweight, and easy to install in tight spaces
• Perfect for marine and RV environments, providing long-lasting performance
• Simple maintenance with easy-to-remove components and smooth, durable finishes
