Tecnoseal Evinrude E-TEC G2 Anode Kit for 200/300 HP Outboards – 4-Piece Set

ID 1404331

$ 138.94

1-2 weeks delivery time

Type:

Zinc
Magnesium
Aluminium

Item:

4 pcs

The Tecnoseal Evinrude E-TEC G2 Anode Kit is a four-piece sacrificial anode set for Evinrude E-TEC G2 200/300 HP outboard motors. Available in zinc (KITETEC-G2), aluminium (KITETEC-G2AL) and magnesium (KITETEC-G2MG), each kit includes one power trim anode (00918 series, 172 × 21 × 34 mm with an additional length of 165 mm), one block anode (00938 series, 46 × 34 × 42 mm), one conical propeller anode (00939 series, Ø58 × 60 mm) and one gearcase plate anode (00940 series, 60 × 22 × 11 mm). The total catalogue weights are 1.72 kg (3.79 lbs) for zinc, 0.74 kg (1.63 lbs) for aluminium and 0.47 kg (1.04 lbs) for magnesium. Tecnoseal lists branded box, blister pack, polybag and skin pack packaging options.

Description
Ask a Question

Tecnoseal Evinrude E-TEC G2 Anode Kit for 200/300 HP Outboards – 4-Piece Set

The Tecnoseal Evinrude E-TEC G2 Anode Kit is a four-piece sacrificial anode set for compatible Evinrude E-TEC G2 200/300 HP outboard motors. It includes anodes for the power trim system, engine block, propeller and gearcase, providing sacrificial corrosion protection for the corresponding outboard components.

The kit is available in three material versions: zinc (KITETEC-G2), aluminium (KITETEC-G2AL) and magnesium (KITETEC-G2MG). Each kit contains four anodes of the selected material, with one piece of each specified component. The catalogue weights are 1.72 kg for zinc, 0.74 kg for aluminium and 0.47 kg for magnesium.

Technical Specifications

Manufacturer	Tecnoseal
Product Type	Outboard Engine Anode Kit
Application	Evinrude E-TEC G2
Engine Compatibility	E-TEC G2 200/300 HP
Available Materials	Zinc, Aluminium, Magnesium
Quantity Supplied	4 Anodes per Kit
Included Components	Power Trim, Block, Propeller and Gearcase Anodes

Available Kit Versions

Tecnoseal Kit Code	Material	Catalogue Weight
KITETEC-G2	Zinc	1.72 kg (3.79 lbs)
KITETEC-G2AL (Osculati 43.317.41)	Aluminium	0.74 kg (1.63 lbs)
KITETEC-G2MG	Magnesium	0.47 kg (1.04 lbs)

Kit Contents

Component	Zinc Kit	Aluminium Kit	Magnesium Kit	Qty
Power Trim Anode	00918	00918AL	00918MG	1
Block Anode	00938	00938AL	00938MG	1
Propeller Anode	00939	00939AL	00939MG	1
Gearcase Anode	00940	00940AL	00940MG	1

Component Dimensions

Component	Dimensions	Mounting Specifications
00918 Series – Power Trim	172 × 21 × 34 mm	Additional length (l1): 165 mm; 5/16" UNC thread
00938 Series – Block	46 × 34 × 42 mm	Ø8.5 mm through-hole; Ø21 mm recess
00939 Series – Propeller	Ø58 × 60 mm	Ø8.5 mm opening; Ø44 mm internal recess
00940 Series – Gearcase	60 × 22 × 11 mm	25 mm mounting hole spacing; Ø7.5 mm holes

Component OEM References

00918 Series – Power Trim: Johnson-Evinrude 5007089 / 433580
00938 Series – Block: Evinrude 355964
00939 Series – Propeller: Evinrude 5009220
00940 Series – Gearcase: Evinrude 357597 / 357507

Packaging Options

The Tecnoseal catalogue lists the following available packaging formats:

Branded box (standard packaging)
Blister pack for hanging display
Polybag
Skin pack for hanging display

Key Features

Four-piece sacrificial anode kit for Evinrude E-TEC G2 outboard motors.
Designed for E-TEC G2 200/300 HP applications.
Available in zinc, aluminium and magnesium versions.
Contains one power trim anode, one block anode, one propeller anode and one gearcase anode.
Four matching material-specific components per kit.
Catalogue kit weights: 1.72 kg (zinc), 0.74 kg (aluminium) and 0.47 kg (magnesium).
Multiple packaging formats listed by Tecnoseal.
