The MARCO UP12/OIL gear pump is a 24V DC self-priming unit for transferring oils or other viscous liquids, with a free-flow output of 15 L/min (without back pressure) and a cut-off pressure of 3 bar. It is dry-run safe, reversible, and draws 6A, with 1/2 inch connections (12.7 mm) including 1/2 inch BSPP. Construction includes a nickel-plated brass housing, stainless steel spindle, bronze gears, FKM seals, and NBR O-rings; dimensions are 222 x 111 x 152 mm and shipping weight is 5.50 kg.
- Description
- Ask a Question
-
UP12/OIL 24V Gear Pump for Oil Transfer
The MARCO 16432013 is an electric, self-priming gear pump designed for transferring oils or other viscous liquids. It uses bronze gears, supports reversible operation, and is built for applications where reliable suction and controlled delivery are required.
Technical Specifications
Voltage 24V Output 15 L/min Flow Condition Free outlet / without back pressure Cut-Off Pressure 3 bar Current Consumption 6 A Self-Priming Up to 2 m Connection 1/2 inch BSPP Connections (Scope of Delivery) 1/2 inch (12.7 mm) Dimensions (H x W x L) 222 x 111 x 152 mm Housing Material Nickel-plated brass Spindle Material Stainless steel Gear Material Bronze Seal Material FKM O-Ring Material NBR Product Portfolio Oil change pumps Shipping Weight 5.50 kg Brand MARCO
Features
- Self-priming design (up to 2 m)
- Dry-run safe
- Reversible operation
- Bronze gear set for oil and viscous-liquid transfer
Product Details
Before putting the pump into operation, verify the compatibility of the pump materials that are in contact with the pumped liquid.
-
