ID
1353892
$ 413.99
1-2 weeks delivery time
-
+
The MARCO 16410013 UP9 gear pump is a 24V DC self-priming transfer unit rated for 12 L/min (free discharge) with a cut-off pressure of 5 bar. It features 3/8 inch connections (3/8 inch BSPP; 9.5 mm noted), draws 3A, and is dry-run safe and reversible. Construction includes a nickel-plated brass housing, bronze gears, a stainless steel spindle, FKM seals, and an NBR O-ring; overall size is 198 x 106 x 175 mm with a shipping weight of 3.40 kg.
- Description
- Ask a Question
-
UP9 24V DC Gear Transfer Pump
The MARCO UP9 gear pump is a self-priming electric transfer pump designed for moving liquids such as diesel. It is built with bronze gears and a reversible motor design, and it is specified as dry-run safe for demanding transfer duties.
Features
- Flow rate of 12 L/min with free discharge (without back pressure)
- Self-priming up to 1.5 m
- Dry-run safe
- Reversible operation
- Ideal for transferring diesel
Technical Specifications
Output 12 L/min Cut-Off Pressure 5 bar Voltage 24V Current Consumption 3 A Self-Priming Up to 1.5 m Connection 3/8 inch BSPP Connections (Noted) 3/8 inch (9.5 mm) Materials Nickel-plated brass housing; stainless steel spindle; bronze gears; FKM seals; NBR O-ring Dimensions (H x W x L) 198 x 106 x 175 mm Product Portfolio Diesel transfer pumps Shipping Weight 3.40 kg Brand MARCO
Product Details
If you are unsure about material compatibility between the pump and the liquid being transferred, verify compatibility of all wetted materials before putting the pump into operation.
-
