ID
1353871
$ 352.05
1-2 weeks delivery time
-
+
The Marco UP1-M flexible impeller pump is a 24V electric self-priming unit rated for 45 L/min (free discharge) with a cut-off pressure of 1.5 bar. It features a 1/2 inch BSPP connection (12.7 mm), draws 7 A, and is self-priming up to 1.5 m. The pump has a nickel-plated brass housing, stainless steel spindle, FKM seals, and an NBR O-ring, is reversible, and has overall dimensions of 210 x 98 x 120 mm (H x W x L) with a shipping weight of 5.10 kg.
- Description
- Ask a Question
-
Marco UP1-M 24V Flexible Impeller Pump
The Marco UP1-M is a 24V flexible impeller pump designed for self-priming transfer duties. It delivers high flow under free-discharge conditions and uses corrosion-resistant construction materials with FKM sealing for applications where material selection is critical.
Technical Specifications
Voltage 24V Flow Rate 45 L/min (free discharge / without back pressure) Cut-Off Pressure 1.5 bar Current Consumption 7 A Self-Priming Up to 1.5 m Connection 1/2 inch BSPP (12.7 mm) Dimensions (H x W x L) 210 x 98 x 120 mm Housing Material Nickel-plated brass Spindle Material Stainless steel Seal Material FKM O-Ring Material NBR Rotation Reversible Impeller Type Flexible nitrile rubber paddle wheel Certificates ISO 8849; ISO 8848 Product Portfolio Impeller pumps Shipping Weight 5.10 kg
Features
- High flow performance: 45 L/min under free-discharge conditions
- Self-priming up to 1.5 m
- Reversible operation
- Nickel-plated brass housing with stainless steel spindle
- FKM seals with NBR O-ring
- Supplied with brush holder with EMI filter, watertight cover, and cable entry
- Available with either an integrated on/off switch or a 3-position switch
Product Details
If there is any uncertainty about material compatibility between the pump components and the pumped liquid, check compatibility before operation.
-
