ID
1353870
$ 290.11
1-2 weeks delivery time
-
+
The Marco UP1 flexible impeller pump (part number 16200213) is a 24V electric self-priming unit rated for 35 L/min (free discharge) with a cut-off pressure of 1.5 bar. It has 1/2 inch connections (1/2 inch BSPP / 12.7 mm) and draws 5 A. Construction details include a nickel-plated brass housing, stainless steel shaft, FKM seals, an NBR O-ring, and a flexible nitrile rubber impeller; the pump is reversible and measures 183 x 95 x 120 mm (H x W x L).
- Description
- Ask a Question
-
Marco UP1 24V Flexible Impeller Pump
The Marco UP1 impeller pump (16200213) is a reversible electric pump designed to move liquid efficiently with a flexible nitrile rubber impeller. It is self-priming and built with corrosion-resistant materials for demanding onboard and industrial-style installations.
Technical Specifications
Voltage 24V Flow Rate 35 L/min (free discharge / without back pressure) Cut-Off Pressure 1.5 bar Self-Priming Up to 1.5 m Current Consumption 5 A Connection 1/2 inch (12.7 mm), 1/2 inch BSPP Dimensions (H x W x L) 183 x 95 x 120 mm Housing Material Nickel-plated brass Shaft Material Stainless steel Seal Material FKM O-Ring Material NBR Impeller Type Flexible nitrile rubber Reversible Yes Certificates ISO 8849, ISO 8848 Shipping Weight 3.60 kg
Features
- Self-priming design
- Reversible operation
- 35 L/min output at free discharge (no back pressure)
- Nickel-plated brass housing with stainless steel shaft
- FKM seals and NBR O-ring
Product Details
- Scope of delivery includes a brush holder with EMI filter, watertight cover, and cable entry
- Available with either an integrated on/off switch or a 3-position switch
-
