The Maxwell RC10-10 Hydraulic 150TDC CW Vertical Anchor Windlass with Drum (Vetus P105443) is a fully automatic hydraulic rope/chain windlass designed for vessels requiring increased deck clearance and independent rope handling. This vertical RC10 Series model supports 10 mm (3/8") DIN 766 chain and 16 mm (5/8") nylon rope, and features a hydraulic drive with performance equivalent to a 1200 W electric system. The 150 TDC configuration enables installation on thicker decks, while the integrated capstan drum allows versatile foredeck operations.
- Description
- Ask a Question
-
Maxwell RC10-10 Hydraulic 150TDC CW Vertical Anchor Windlass with Drum (Vetus P105443)
The Maxwell RC10-10 Hydraulic is a fully automatic vertical rope/chain anchor windlass from the Maxwell RC10 Series, engineered for demanding anchoring applications on cruising yachts, expedition vessels, and professional craft. This version features an increased Total Deck Clearance of 150 TDC, allowing installation on vessels with thicker deck structures or specific mounting requirements.
Manufactured from marine-grade stainless steel (AISI 316) and chromed bronze, the RC10-10 offers excellent corrosion resistance and long-term durability. The patented Wave Design™ chainwheel, together with a heavy-duty stainless steel pressure arm and preloaded spring system, ensures secure control of rope, chain, and the rope-to-chain splice during anchoring operations.
This capstan version is equipped with a fluted stainless steel drum, enabling independent rope handling operations in addition to standard anchor deployment and retrieval. The hydraulic drive system delivers smooth, consistent performance equivalent to a 1200 W electric motor, making this windlass suitable for vessels equipped with onboard hydraulic systems.
Specification Value Vetus Part Number P105443 Model RC10-10 Hydraulic Series Maxwell RC10 Series Drive Type Hydraulic (≈1200 W equivalent) Installation Type Vertical Operation Automatic rope / chain Drum Yes, fluted stainless steel capstan drum Total Deck Clearance 150 TDC Maximum Pull / Lift Approximately 850 kg Static Hold Approximately 1500 kg Chain Speed (Retrieval) Approximately 24 m/min Rope Speed (Retrieval) Approximately 20 m/min Rotation CW (clockwise)
Rope and Chain Compatibility
- Short link chain: 10 mm (3/8") DIN 766
- Chain diameter: 10 mm
- Recommended rope types: 3-strand or 8-plait nylon
- Rope diameter: 16 mm (5/8")
Recommended Vessel Application
- Cruising and expedition yachts
- Motor vessels with hydraulic systems
- Professional and commercial craft requiring increased deck clearance
Key Features
- Hydraulic vertical automatic rope/chain anchor windlass
- Integrated capstan drum for independent rope handling
- Increased 150 TDC deck clearance
- Wave Design™ chainwheel for smooth and controlled anchoring
- Marine-grade AISI 316 stainless steel and chromed bronze construction
Operational Notes
- The windlass must be used in conjunction with a chain stopper and/or alternative snubbing device to remove load from the windlass while at anchor.
- A chain stopper or alternative snubbing system must also be used to secure the anchor in the fully raised position while the vessel is under way.
-
