ID
1345391
$ 469.18
1-2 weeks delivery time
-
+
Exalto EWT 223BD 24V wiper motor with a 55° wiping angle for bulkhead installation up to 125 mm. MD1 pendulum wiper with self-parking, interval function, and reliable 25 Nm torque output.
- Description
- Ask a Question
-
Exalto EWT Wiper 223BD 24V 55° 25Nm Bulkhead 125mm
The Exalto EWT 223BD 24V wiper motor with a 55° angle of view is built for bulkhead mounting with a wall thickness of 125 mm. This MD1 series wiper features pendulum wiping, self-parking, and speed interval. With a consistent torque of 25 Nm and compatibility with arms and blades up to 750 mm, it ensures dependable wiping performance.
Key Features
- Pendulum wiping system
- 55° angle of view
- Self-parking resting position
- Speed interval function
- MD1 series compatibility
Technical Data
Article Code XA2166.50-55 Sales Unit 1 piece EAN Code 8720763541658 Brand Exalto Wiper Technologies B.V. Series MD1 Suitable For MD1 series Arm Type MD1 Pendulum Driven Axles 1 Angle Of View 55° Voltage 24 V Type VDC Power 36 W Torque 25 Nm High Speed 60 rpm Low Speed 40 rpm Maximum Ampèrage 1.5 A Recommended Fuse Rating 4 A Ungrounded yes Drive Shaft Diameter 19 mm Shaft Length 182 mm Centre Distance HoH 50 mm Support Diameter 6.4 mm Maximum Arm Length 750 mm Maximum Blade Length 750 mm Product Width 170 mm Product Depth 288 mm Product Height 90 mm Wall Thickness 125 mm
Brand: Exalto Wiper Technologies B.V. (Article code: XA2166.50-55)
-
