ID
1345397
$ 469.18
1-2 weeks delivery time
-
+
Exalto EWT 223BD 24V wiper motor delivering an 85° wiping angle for wide coverage. Bulkhead-mounted MD1 pendulum wiper with self-parking, interval mode, and constant 25 Nm torque.
- Description
- Ask a Question
-
Exalto EWT Wiper 223BD 24V 85° 25Nm Bulkhead 125mm
The Exalto EWT 223BD 24V wiper motor with an 85° angle of view provides wide wiping coverage for bulkhead-mounted installations with a wall thickness of 125 mm. This MD1 series pendulum wiper includes self-parking and speed interval functions and delivers a constant 25 Nm torque for reliable operation.
Key Features
- 85° pendulum wiping angle
- Self-parking resting position
- Speed interval function
- Bulkhead mounting design
- MD1 series compatibility
Technical Data
Article Code XA2166.50-85 Sales Unit 1 piece EAN Code 8720763541719 Brand Exalto Wiper Technologies B.V. Series MD1 Suitable For MD1 series Arm Type MD1 Pendulum Driven Axles 1 Angle Of View 85° Voltage 24 V Type VDC Power 36 W Torque 25 Nm High Speed 60 rpm Low Speed 40 rpm Maximum Ampèrage 1.5 A Recommended Fuse Rating 4 A Ungrounded yes Drive Shaft Diameter 19 mm Shaft Length 182 mm Centre Distance HoH 50 mm Support Diameter 6.4 mm Maximum Arm Length 750 mm Maximum Blade Length 750 mm Product Width 170 mm Product Depth 288 mm Product Height 90 mm Wall Thickness 125 mm
Brand: Exalto Wiper Technologies B.V. (Article code: XA2166.50-85)
-
