ID
1345392
$ 469.18
1-2 weeks delivery time
-
+
Exalto EWT 223BD 24V wiper motor offering a 60° angle of view for extended wiping coverage. Designed for 125 mm bulkhead mounting, with MD1 pendulum action, self-parking, interval function, and 25 Nm torque.
- Description
- Ask a Question
-
Exalto EWT Wiper 223BD 24V 60° 25Nm Bulkhead 125mm
The Exalto EWT 223BD 24V wiper motor with a 60° angle of view offers extended wiping coverage for bulkhead installations with a wall thickness of 125 mm. This MD1 series pendulum wiper combines self-parking and speed interval with a powerful 25 Nm torque for reliable operation.
Key Features
- 60° pendulum wiping angle
- Self-parking function
- Speed interval available
- Bulkhead mounting design
- Single driven axle
Technical Data
Article Code XA2166.50-60 Sales Unit 1 piece EAN Code 8720763541665 Brand Exalto Wiper Technologies B.V. Series MD1 Suitable For MD1 series Arm Type MD1 Pendulum Driven Axles 1 Angle Of View 60° Voltage 24 V Type VDC Power 36 W Torque 25 Nm High Speed 60 rpm Low Speed 40 rpm Maximum Ampèrage 1.5 A Recommended Fuse Rating 4 A Ungrounded yes Drive Shaft Diameter 19 mm Shaft Length 182 mm Centre Distance HoH 50 mm Support Diameter 6.4 mm Maximum Arm Length 750 mm Maximum Blade Length 750 mm Product Width 170 mm Product Depth 288 mm Product Height 90 mm Wall Thickness 125 mm
Brand: Exalto Wiper Technologies B.V. (Article code: XA2166.50-60)
-
