ID
1345396
$ 469.18
1-2 weeks delivery time
-
+
Exalto EWT 223BD 24V wiper motor with an 80° angle of view for professional bulkhead applications up to 125 mm. MD1 pendulum wiper with self-parking, interval function, and 25 Nm torque supporting long blades.
- Description
- Ask a Question
-
Exalto EWT Wiper 223BD 24V 80° 25Nm Bulkhead 125mm
The Exalto EWT 223BD 24V wiper motor with an 80° angle of view is designed for heavy-duty bulkhead installation with a wall thickness of 125 mm. This MD1 series pendulum wiper features self-parking and speed interval functionality. With a torque output of 25 Nm and support for long wiper arms and blades up to 750 mm, it delivers reliable performance for professional marine and industrial applications.
Key Features
- Pendulum wiping system
- 80° angle of view
- Self-parking function
- Speed interval available
- Bulkhead mounting for 125 mm wall thickness
Technical Data
Article Code XA2166.50-80 Sales Unit 1 piece EAN Code 8720763541702 Brand Exalto Wiper Technologies B.V. Series MD1 Suitable For MD1 series Arm Type MD1 Pendulum Driven Axles 1 Angle Of View 80° Voltage 24 V Type VDC Power 36 W Torque 25 Nm High Speed 60 rpm Low Speed 40 rpm Maximum Ampèrage 1.5 A Recommended Fuse Rating 4 A Ungrounded yes Drive Shaft Diameter 19 mm Shaft Length 182 mm Centre Distance HoH 50 mm Support Diameter 6.4 mm Maximum Arm Length 750 mm Maximum Blade Length 750 mm Product Width 170 mm Product Depth 288 mm Product Height 90 mm Wall Thickness 125 mm
Brand: Exalto Wiper Technologies B.V. (Article code: XA2166.50-80)
-
