ID
1345398
$ 469.18
1-2 weeks delivery time
-
+
Exalto EWT 223BD 24V wiper motor with a full 90° angle of view for maximum wiping area. Designed for 125 mm bulkhead mounting, featuring MD1 pendulum wiping, self-parking, interval function, dual speed, and 25 Nm torque.
- Description
- Ask a Question
-
Exalto EWT Wiper 223BD 24V 90° 25Nm Bulkhead 125mm
The Exalto EWT 223BD 24V wiper motor with a full 90° angle of view delivers maximum wiping coverage for heavy-duty bulkhead installations with a wall thickness of 125 mm. This MD1 series pendulum wiper features self-parking, speed interval, and dual speed operation. With a torque output of 25 Nm, it is suitable for demanding professional environments.
Key Features
- Maximum 90° pendulum wiping angle
- Self-parking function
- Speed interval available
- High and low speed operation
- Bulkhead mounting design
Technical Data
Article Code XA2166.50-90 Sales Unit 1 piece EAN Code 8720763541726 Brand Exalto Wiper Technologies B.V. Series MD1 Suitable For MD1 series Arm Type MD1 Pendulum Driven Axles 1 Angle Of View 90° Voltage 24 V Type VDC Power 36 W Torque 25 Nm High Speed 60 rpm Low Speed 40 rpm Maximum Ampèrage 1.5 A Recommended Fuse Rating 4 A Ungrounded yes Drive Shaft Diameter 19 mm Shaft Length 182 mm Centre Distance HoH 50 mm Support Diameter 6.4 mm Maximum Arm Length 750 mm Maximum Blade Length 750 mm Product Width 170 mm Product Depth 288 mm Product Height 90 mm Wall Thickness 125 mm
Brand: Exalto Wiper Technologies B.V. (Article code: XA2166.50-90)
-
