ID
1331437
$ 1,295.77
1-2 weeks delivery time
-
+
The Jabsco 37255-0094 Quiet Flush 24V toilet conversion kit upgrades compatible manual toilets to an electric flushing system with low-noise operation, a single-button flush actuator with dual-function water level control, and a PAR-Max 4 self-priming flush pump that can supply sea, lake, or river water for bowl rinsing. Designed for 24V DC systems, it combines a high-capacity waste macerator and bowl discharge pump with 19 mm inlet and 25 mm discharge connections, includes an adaptor for 38 mm waste plumbing, and is supplied as a complete kit with motorized base assembly, bowl gasket, fasteners, hoses, control switch, and port adaptor.
- Description
- Ask a Question
-
Jabsco 37255-0094 24V Quiet Flush Toilet Conversion System
The Jabsco 37255-0094 is a 24V conversion kit designed to upgrade compatible manual marine toilets to a Quiet Flush electric flushing setup. It delivers convenient single-button operation, quiet running performance, and an integrated flushing and discharge solution that reduces the effort of manual pumping.
Application
- Conversion kit for upgrading manual toilets to electric flushing systems
- Marine applications
- Also described for marine or RV toilet upgrade use
- Designed for sea, lake, or river water bowl rinsing (via supplied self-priming flush pump)
Compatibility
- Manual Jabsco Toilet 29090
- Manual Jabsco Toilet 29120
- Any model with a “standard” bowl configuration (95.3 mm bolt circle), 4-hole pattern in the base
Technical Specifications
Voltage 24 Volts (24V DC) Amperage 5 A Recommended Fuse Size 15 A Water Consumption Approximately 1–2 liters per flush Inlet Connection 19 mm (3/4 in) inlet hose Discharge Connection 25 mm (1 in) discharge hose Waste Plumbing Adaptor Adaptor included for 38 mm (1-1/2 in) waste plumbing Dimensions (H x W x L) 101 x 181 x 337 mm Dimensions (H x W x D) 355 x 415 x 333 mm Shipping Weight 6.90 kg Order Number 00320052 Supplier Code 37255-0094 Barcode 671880521215 Product Portfolio Electric Toilets
Product Details
- Low-noise operation to minimize disturbance onboard
- Single-button flush actuator with dual-function water level control switch
- PAR-Max 4 self-priming pump to provide sea or lake water to rinse the toilet bowl (also described for sea or river water flush)
- High-capacity waste macerator and bowl discharge pump for efficient waste handling and discharge
Package Includes
- Complete motorized base assembly
- Bowl gasket
- Four bolts and washers
- PAR-Max 4 flush pump
- 19 mm (3/4 in) white hose
- 25 mm (1 in) discharge port adaptor
- Control switch
-
