ID
1374625
$ 13.91
1-2 weeks delivery time
Size:
- 3/8"
- 1/2"
- 3/4"
- 1"
- 1 1/4"
- 1 1/2"
- 2"
- 2 1/2"
- 3"
- 4"
The Osculati 17.228 Series Full Port Ball Valves are manufactured from nickel-plated brass and designed for full-flow shut-off applications. Featuring long threads compliant with ISO 9093 regulations and a stainless steel handle, these PN25-rated valves are available in thread sizes from 3/8" to 4". The series provides unrestricted flow through the valve body and is suitable for marine plumbing, seawater, freshwater, and fluid transfer systems.
- Description
- Ask a Question
-
Osculati 17.228 Series – Nickel-Plated Brass Full Port Ball Valve, PN25, 3/8" to 4"
The Osculati 17.228 Series Ball Valves are manufactured from nickel-plated brass and designed for full-flow shut-off applications in marine and industrial piping systems. The full port construction allows maximum flow through the valve, minimizing restriction within the pipeline.
The valves feature long threads compliant with ISO 9093 regulations and are equipped with a stainless steel operating handle for reliable operation and corrosion resistance.
Key Features
- Nickel-plated brass construction
- Full port design for unrestricted flow
- PN25 pressure rating
- Long threads according to ISO 9093 regulations
- Stainless steel operating handle
- Designed for full-flow shut-off applications
- Available in sizes from 3/8" to 4"
Available Variants
Osculati Code Thread Size A (mm) B (mm) 17.228.01 3/8" 11 41 17.228.02 1/2" 12 50 17.228.03 3/4" 13 56 17.228.04 1" 14 65 17.228.05 1-1/4" 18 80 17.228.06 1-1/2" 20 90 17.228.07 2" 23 105 17.228.08 2-1/2" 23 130 17.228.09 3" 28 150 17.228.10 4" 30 180
Applications
- Marine plumbing systems
- Seawater systems
- Freshwater systems
- Through-hull installations
- Fluid transfer systems
- Tank and piping isolation
- General shut-off applications
Technical Information
Property Specification Material Nickel-Plated Brass Handle Material Stainless Steel Valve Type Full Port Ball Valve Pressure Rating PN25 Thread Range 3/8" to 4" Thread Standard ISO 9093 Long Threads -
