Clamcleat CL277 Side Entry Racing Micros Starboard Cleats for 1–4 mm Rope

ID 1395014

$ 11.54

1-2 weeks delivery time

Color:

Silver
Hard Anodised

Clamcleat CL277 Side Entry Racing Micros cleats are compact aluminium cleats designed for 1–4 mm (3/64–5/32") ropes. The side-entry fairlead allows the line to be hooked in quickly for cleating and removed easily when required, while the advanced tooth profile provides secure holding. An integral becket supports 2:1 rigging without extra fittings. Available in silver stove-enamel or hard-anodised finishes.

Description
Ask a Question

Clamcleat CL277 Side Entry Racing Micros Starboard Cleats for 1–4 mm Rope, Silver or Hard Anodised

Clamcleat CL277 Side Entry Racing Micros is a compact aluminium rope cleat designed for ropes from 1 to 4 mm (3/64–5/32").

The side-entry fairlead allows the rope to be hooked into the cleat quickly for immediate use and removed easily when required. The advanced tooth profile provides secure holding across a range of small-diameter ropes.

An integral becket beneath the cleat allows 2:1 rigging without the need for an additional rope attachment point.

The CL277 is suitable for canoe and kayak seat and rudder lines, dinghy tiller lines and other compact rope-control applications.

The range is available in two finishes: CL277 with a silver stove-enamel finish and CL277AN with a hard-anodised finish for increased surface durability and wear resistance.

Product Features

Brand: Clamcleat
Series: Side Entry Racing Micros
Models: CL277 and CL277AN
Orientation: Starboard
Product type: Side-entry aluminium rope cleat with becket
Material: Aluminium
Rope diameter: 1–4 mm (3/64–5/32")
Side-entry fairlead for quick rope engagement and removal
Advanced tooth profile for secure rope holding
Integral becket for 2:1 rigging
No additional rope fixing point required for 2:1 purchase
Compact and lightweight design
Suitable for canoe and kayak seat and rudder lines
Suitable for dinghy tiller lines
Silver stove-enamel and hard-anodised finish options

Technical Specifications

Parameter	Specification
Rope Diameter	1–4 mm (3/64–5/32")
Material	Aluminium
Hole Centres	24 mm
Length	44 mm
Width	14 mm
Height	17 mm
Bolt Size	M3
Screw Size	3 mm / No. 4
Weight	Approx. 12 g
Rigging Advantage	2:1 via integrated becket

Available Variants

Model	Finish	Rope Diameter
CL277	Silver stove enamel	1–4 mm
CL277AN	Hard anodised	1–4 mm

Installation Note

When fitting the aluminium cleat to carbon fibre structures, use a suitable barrier compound or insulating components to help prevent galvanic corrosion.
