ID
1360782
$ 24.89
1-2 weeks delivery time
-
+
The Barton N10160 is a Size 0 single cheek block with a 20 mm ball bearing sheave, designed for ropes up to 6 mm. Weighing 15 g, it provides smooth low-friction operation with a working load of 275 kg and break load of 550 kg, ideal for fixed mounting in dynamic control systems.
- Description
- Ask a Question
-
Barton N10160 – Single Cheek Block Size 0 20mm, Ball Bearing, Ø20mm Sheave, Max Rope 6mm
The Barton N10160 Single Cheek Block is a compact Size 0 (20 mm) block designed for fixed mounting applications, featuring a ball bearing sheave for smooth and efficient line handling under load.
The cheek block construction allows direct installation onto flat surfaces such as decks, masts, or bulkheads. The ball bearing system reduces friction, making it especially suitable for frequently adjusted control lines and dynamic rigging setups on dinghies, day boats, and small craft.
Key Features
- Single cheek block for fixed mounting
- Ball bearing system for low-friction, high-efficiency operation
- Ultra-lightweight construction – 15 g
- Designed for dynamic and frequently adjusted lines
- Compact size for installation in confined spaces
Technical Specifications
Part Number N10160 Block Type Cheek Block (Fixed Mount) Size Size 0 (20 mm) Sheave Diameter 20 mm x 8 mm (25/32" x 5/16") Bearing Type Ball Bearing Number of Sheaves Single Max Rope Diameter 6 mm (1/4") Safe Working Load (SWL) 275 kg (606 lbs) Break Load 550 kg (1210 lbs) Max Rolling Load 130 kg (286 lbs) Weight 15 g Dimensions 55 × 21 × 16 mm
Applications
- Deck and mast-mounted line routing
- Dynamic control and trimming systems
- Dinghies and performance sailing boats
- Compact rigging installations
The Barton Size 0 ball bearing cheek blocks are engineered for high-performance, low-friction operation, ensuring efficient handling of control lines in demanding sailing conditions.
-
