Barton N00160 – Single Cheek Block Size 0 20mm, Plain Bearing, Ø20mm Sheave, Max Rope 6mm

ID 1360630

$ 13.87

1-2 weeks delivery time

- +

Add to cart

The Barton N00160 is a Size 0 single cheek block with a 20 mm plain bearing sheave, designed for ropes up to 6 mm. Weighing 17 g, it offers a working load of 275 kg and break load of 550 kg, providing a compact fixed-mount solution for deck-mounted line routing.

Description
Ask a Question

Barton N00160 – Single Cheek Block Size 0 20mm, Plain Bearing, Ø20mm Sheave, Max Rope 6mm

The Barton N00160 Single Cheek Block is a compact and lightweight Size 0 (20 mm) block designed for fixed mounting applications. Featuring a plain bearing sheave, it provides reliable performance under load with a simple and robust construction.

The cheek block design allows for direct mounting onto flat surfaces such as decks, masts, or bulkheads, making it ideal for controlled line routing in confined spaces. This block is particularly suited for dinghies, day boats, and small craft, as well as auxiliary rigging on larger yachts.

Key Features

Single cheek block for fixed mounting applications
Plain bearing for dependable and durable operation
Compact and lightweight – only 17 g
Ideal for deck, mast, or bulkhead installation
Designed for efficient line guidance in tight spaces

Technical Specifications

Part Number	N00160
Block Type	Cheek Block (Fixed Mount)
Size	Size 0 (20 mm)
Sheave Diameter	20 mm x 8 mm (25/32" x 5/16")
Bearing Type	Plain Bearing
Number of Sheaves	Single
Max Rope Diameter	6 mm (1/4")
Safe Working Load (SWL)	275 kg (606 lbs)
Break Load	550 kg (1210 lbs)
Weight	17 g
Dimensions	55 × 21 × 16 mm

Applications

Deck-mounted line routing systems
Mast and boom installations
Dinghies and small sailing boats
Control lines and light-duty rigging

The Barton Size 0 cheek block range delivers efficient line control in fixed positions, combining lightweight construction with reliable strength for a wide range of marine applications.
