ID
1317197
$ 10,863.11
1-2 weeks delivery time
-
+
The Victor Pumps S88G31T Flange 15.0KW is a robust self-priming centrifugal pump with DN 80 flange connections, designed for deck wash and bilge applications in commercial shipping. It efficiently handles clean and contaminated liquids with coarse particles up to 35 mm, delivering flow rates up to 97,000 liters per hour at 35 m head, powered by a 15.0 kW motor running at 2900 rpm. The pump features a cast steel impeller and wearing plate, cast iron housing, stainless steel shaft, and a SiC on ceramic mechanical seal with Viton in an oil bath, with protection class IP68 and no ATEX certification.
- Description
- Ask a Question
-
Victor Pumps S88G31T Flange 15,0KW
Equipped with DN 80 flange connections, this pump delivers the same robust performance for deck wash and bilge applications, handling liquids with coarse particles efficiently in commercial shipping.
- Type: S
- Colour: blue
- Pump type: self-priming centrifugal pump
- Impeller type: open impeller
- Motor type: short circuit motor
- Fuse: NOT inbuilt
- Insulation class: IP55
- Shaft seal: SiC on ceramic mechanical seal with Viton, in oil bath
- Material impeller: cast steel
- Material wearing plate: cast steel
- Material pump housing: cast iron
- Material pump shaft: stainless steel
- Liquids: clean and contaminated liquids with coarser particles such as water, sea water, gas oil, etc.
- Flow rates by head:
- 35 m head: 97,000 litres per hour
- 40 m head: 70,000 litres per hour
- 45 m head: 55,000 litres per hour
- 50 m head: 32,000 litres per hour
- Dimensions (LxWxH): 819 x 468 x 367 mm
- Weight: 140 kg
- Amperage: 30.0 A
- Shaft power: 15.0 kW, 20.4 hp, 2900 rpm
- Product code: 92.09.089
- Suction head: 8.0 m
- Pipe diameter pressure: DN 80 Flange
- Pipe diameter suction: DN 80 Flange
- Pump type: Dry set-up pump, self-priming
- Medium: Water and water with coarse components
- Particle size: 35 mm
- Max discharge head: 52.0 m
- Voltage: 400 V
- Current type: AC
- Frequency: 50 Hz
- Protection class: IP68
- ATEX: No
- Separate float switch: Not included
- Free flow: 100,000 L/hour
- Capacity at 5 meter: 100,000 L/hour
-
