The Victor Pumps S105G31T 5.5KW 1450TPM is a reliable self-priming centrifugal pump widely used for deck washing and bilge pumping in commercial shipping. It handles clean and contaminated liquids with coarse particles up to 45 mm, providing a flow rate of 105,000 liters per hour at 10 meters head. The pump has 4" internal thread connections, a cast steel impeller, cast iron housing, stainless steel shaft, and a SiC on ceramic mechanical seal with Viton, operating at 1450 rpm with a 5.5 kW motor and IP68 protection class.
- Description
- Ask a Question
-
Victor Pumps S105G31T 5,5KW 1450TPM
This reliable pump is widely used for deck washing and bilge pumping in commercial shipping. It handles both clean and contaminated liquids containing coarser particles like seawater and gas oil effectively.
- Type: S
- Colour: blue
- Pump type: self-priming centrifugal pump
- Impeller type: open impeller
- Motor type: short circuit motor
- Fuse: NOT inbuilt
- Insulation class: IP55
- Shaft seal: SiC on ceramic mechanical seal with Viton, in oil bath
- Material impeller: cast steel
- Material wearing plate: cast steel
- Material pump housing: cast iron
- Material pump shaft: stainless steel
- Liquids handled: clean and contaminated liquids with coarser particles such as water, sea water, gas oil etc.
- 10 metres head flow rate: 105,000 litres per hour
- Connections: 4" internal thread
- Dimensions (LxWxH): 723 x 354 x 471 mm
- Weight: 128 kg
- Amperage: 11.7 A
- Shaft power: 5.5 kW, 7.3 hp, 1450 rpm
- Product code: 92.09.105
- Suction head: 8.0 m
- Pipe diameter pressure: 4"
- Pipe diameter suction: 4"
- Pump type: Dry set-up pump, self-priming
- Medium: Water and water with coarse components
- Particle size capacity: 45 mm
- Maximum discharge head: 13.5 m
- Voltage: 400 V
- Current: AC
- Frequency: 50 Hz
- Protection class: IP68
- ATEX: No
- Free flow rate: 135,000 L/hour
- Capacity at 5 meters: 135,000 L/hour
-
