The Toilet 70 Black Water Pump variant powered by a 400V short circuit motor is highly effective for pumping contaminated water containing solids, higher viscosity substances, or liquids with increased specific gravity. It is designed for black water tanks and faeces without coarse or hard parts, featuring a membrane pump and a maximum discharge head of 7 meters.
- Description
- Ask a Question
-
Toilet 70, Black Water Pump 400V
This Toilet 70 pump variant is powered by a short circuit motor operating at 400 volts, making it highly effective for pumping contaminated water containing solids, higher viscosity substances, or liquids with increased specific gravity. It is suitable for black water tanks and faeces without coarse or hard parts.
- Type: TOILET
- Colour: black
- Pump type: self-priming centrifugal pump
- Impeller type: membrane
- Motor type: short circuit motor with 400 volt
- Fuse: none
- Shaft seal: n/a
- Material membrane: santoprene
- Material pump housing: plastic
- Material pump shaft: n/a
- Liquids handled: water with solids, higher viscosity or specific gravity
- Dimensions (LxWxH): approx. 470 x 250 x 340 mm
- Weight: approx. 18 kg
- Amperage: 400 V, 1.1 A
- Shaft power: 0.37 kW, 0.5 HP, 1500 rpm
- Product code: 92.91.640
- Suction head: 4.0 m
- Pipe diameter pressure: 35/40 mm Adaptor
- Pipe diameter suction: 35/40 mm Adaptor
- Pump type: Membrane pump
- Medium: Water and water with oil (sludge)
- Particle size: 25 mm
- Discharge head Max.: 7.0 m
- Voltage: 400 V
- Current: AC
- Frequency: 50 Hz
- Fuel: -
- Protection class: IP68
- ATEX: No
- Separate float switch: -
- Free flow: 4200 L/Hour
- Capacity at 5 meter: 250 L/hour
-
