Johnson Pump 11-45874-03F - FIP25 Bronze HD Self-Priming Impeller Pump for Marine Transfer

ID 1331078

$ 3,329.49

1-2 weeks delivery time

- +

Add to cart

The Johnson Pump FIP25-Bronze heavy-duty impeller pump delivers 158 l/min capacity with a 400V single-phase motor for consistent marine fluid transfer. Its bronze housing supports seawater use, while self-priming up to 5 m and a 25 m maximum head help maintain dependable suction lift and discharge performance. A 1" connection simplifies integration, and the mechanical seal plus 13.2 kg build target durable service across 3°C to 80°C operating temperatures.

Description
Ask a Question

Johnson FIP25 Bronze Heavy-Duty Impeller Pump With 400V Motor

The Johnson Pump FIP25-Bronze is a heavy-duty impeller pump built for dependable fluid transfer where a robust bronze pump body and strong suction capability are required. Powered by a 400V single-phase motor, it maintains high, steady flow while supporting self-priming operation for practical marine installations.

Application

Marine fluid transfer and circulation applications
Suitable for seawater use

Technical Specifications

Article Number	66114587403F
Model	FIP25-Bronze
EAN	8719182071686
Material	Bronze housing
Voltage	400V (1-Phase)
Capacity	158 l/min
Self-Priming	Up to 5 m
Maximum Head	25 m
Connection	1"
Operating Temperature	3°C - 80°C
Weight	13.2 kg

Product Details

Pump type: HD impeller pump
Seal: Mechanical seal
Construction: Bronze pump housing

Features

High flow capacity of 158 l/min for efficient transfer
Self-priming capability up to 5 m for easier installation and reliable suction lift
Maximum head of 25 m to support demanding discharge requirements
400V single-phase motor for consistent operation
1" connection for straightforward plumbing integration
Operating temperature range from 3°C to 80°C
