ID
1332439
$ 1,728.47
1-2 weeks delivery time
-
+
The Johnson Pump 10-13656-03 circulation pump unit (Johnson CM10) delivers continuous-duty fluid circulation for water and water/glycol mixtures, with support for 12/24V DC operation and IP67 protection for demanding installations. It handles up to 60% glycol content, works from -40°C to +100°C, and supports up to 2.5 bar system pressure, while offering hose connections in 16 mm or 20 mm (3/4 in) to simplify integration.
- Description
- Ask a Question
-
Johnson Pump 10-13656-03 CM10 Circulation Unit
The Johnson Pump 10-13656-03 is a compact circulation pump designed for circulating cooling liquids such as water and water/glycol mixtures. Built for continuous running and protected to IP67, it supports reliable operation in harsh environments while offering flexible mounting and common hose connection sizes.
Application
- Water/glycol mixture (maximum 60% glycol)
- Pure fresh water
Technical Specifications
Brand / Series Johnson Pump CM10 Part Number 10-13656-03 Model / Code C096 Voltage (As Listed) 27.2 V Motor Supply 12/24 V DC Ingress Protection IP67 Motor Type Permanent Magnet, Ball-Bearing Motor Designed For Continuous Operation Maximum Power Consumption 14 W (CM10); 27 W (CM30) Fluid Temperature Range Min -40 °C / Max +100 °C Maximum System Pressure 2.5 bar Dry Running Limit Maximum 30 minutes Hose Connection Ø 16 mm or Ø 20 mm (3/4 in) Diameter (As Listed) DIA25 Length 177 mm (6.97 in) Width 68 mm (2.68 in) Height 85 mm (3.35 in) Weight 0.53 kg (1.2 lb)
Product Details
- Pump housing: PPA plastic
- Impeller: PPA plastic
- Shaft: Stainless steel
- Material (as listed): Brass
- Mounting: Universal bracket, flat mounting
Features
- IP67-protected motor for robust operation
- Permanent-magnet, ball-bearing motor design
- Designed for continuous duty
- Supports water and water/glycol cooling liquids (up to 60% glycol)
-
